MarSurf UD 130 / LD 130 / LD 260

Combined Contour and Surface Measuring Station
UD 130 / LD 130 / LD 260 MarSurf
Surface Measuring Instruments
DESCRIPTION Combined contour and surface measuring station
MarSurf UD 130
The MarSurf UD 130 closes the
gap between the high-end solution
MarSurf LD 130/LD 260 and the
new standard combination mea-
suring station MarSurf VD140/280
with two probe systems.

The technical specifications of the
MarSurf UD 130 are based on
theinterferometric probe system
and the positioning speeds that
reduce themeasuring time for each
workpiece.
MarSurf LD 130 / LD 260. A step
into a new dimension
Combined contour and roughness
measurements in just one step
comes courtesy of proven cutting- TECHNICAL DATA
edge technology from Mahr
metrology. The MarSurf LD 130 UD 130 LD 130 LD 260
and MarSurf LD 260 measuring Traversing lengths 0.1 mm to 130 mm 0.1 mm – 130 mm 0.1 mm – 260 mm
stations have been systematically
developed to draw on the Measuring force 1 mN to 30 mN, 0.5 mN to 30 mN, 0.5 mN to 30 mN,
experience from the first software-adjustable software-adjustable software-adjustable
generation of equipment. Resolution 2 nm 0.8 nm 0.8 nm
Measuring speed 0.1 mm/s to 5 mm/s; 0.02 mm/s to 10 mm/s; 0.02 mm/s to 10 mm/s;
• Roughness and contour in for roughness measurements for roughness measurements for roughness measurements
just one step 0.1 mm/s to 0.5 mm/s are 0.1 mm/s to 0.5 mm/s is 0.1 mm/s to 0.5 mm/s is
• High measuring and positioning recommended recommended recommended
speed cuts measuring times Positioning speed 0.1 mm/s to 30 mm/s 0.02 mm/s to 200 mm/s 0.02 mm/s to 200 mm/s
dramatically
• Innovative probe system removal
• Quick and reliable probe arm APPLICATIONS ACCESSORIES
exchange with simultaneous
probe arm detection by Machine building • ST 750 measuring stand
magnetic holder • Roller bearings, threads, threaded rods, • Parallel V-block
• Long measuring length up to ball screws, shafts, racks, ball heads, valves • V-block, equipment table
260 mm (MarSurf LD 260) with a • Measuring cabinet
measuring stroke of 13 mm (100 Measurement close to the production area • Extensive range of probe arms
mm probe arm length) or 26 mm • Contour and surface roughness measurement in
(200 mm probe arm length) semi-automatic and fully automatic operation Software options
• Modular construction for ease • Profile processing
of maintenance Automotive industry • Dominant waviness (WDc) for MarWin
• No need to fully dismantle • Engine parts including cylinder block, cylinder head, • ISO 13565– 3 surface parameters
the measuring stand for crankshaft, camshaft, valves, steering, gearbox, • User defined parameters
maintenance injection systems, turbocharger • Topography
• Topography with MfM
Supplied with: Medicine • Thread evaluation
• Contour and surface roughness measurement for hip • Chamfer evaluation
• MarSurf XCR 20 including and knee endoprostheses, contour measurement for (in accordance with Bosch standard)
midrange LD, MarWin software medical screws, contour and surface roughness • QS-STAT / QS-STAT Plus
Easy Roughness & Contour, measurement for dental implants • Digital I/O set
Mahr license key
• TFT monitor Optics
• MCP 21 manual control panel • Contour and surface roughness measurement
• MarSurf LD 130 or LD 260 drive of aspherical lenses
unit including LP D 14– 10– 2/60
LP D 14– 10– 500 probe system
and probe arms
• Calibration standard for contour
1, accuracy class 1
• MarSurf ST 500 CNC measuring
stand with 700 mm x 550 mm
granite plate
(including control module)
• Dampening element set
• CT 300 XY table
For more information, please visit our website: www.mahr.com

542 MarSurf | Surface Measuring Instruments
