MarSurf GD 140 / GD 280

Roughness Measuring Station

DESCRIPTION

MarSurf GD: The new refer ence
measuring station for roughness
and waviness
The new measuring stations of the
MarSurf GD series from Mahr set
new standards. In addition to sur-
face roughness evaluations, profile
and waviness evaluations can
also be carried out. With the new
MarSurf GD series, manufacturing
companies are reaching a new di-
mension in order to reliably secure
and improve the production quality
of workpieces in the measuring
room or close to production.
The new measuring station concept
combines speed, reliability and
flexibility. The aim is to increase the
profitability of the system for your
company. TECHNICAL DATA
The measuring stations are operat-
ed with the user-friendly MarWin MarSurf GD 140 / 280
software (MarWin EasyRoughness Measuring range 500 µm (±250 µm) for probe arm length 45 mm
or MarWin Profes sionalRoughness) 1500 µm (±750 µm) for probe arm length 135 mm
Resolution Measuring range 1: 7.6 nm
Innovative technologies: Measuring range 2: 0.76 nm
• Fast axes Guide deviation 0.07 µm / 20 mm
• Positioning speeds up to 200 0.2 µm / 60 mm
mm/s in X 0.4 µm / 140 mm
• 40 x faster than its predecessor Measuring speed Up to 10 mm/s
MarSurf GD 120 Positioning speed 0.02 – 200 mm/s (in X)
• The Z-axis is fully CNC-capable Probe arm length 45 mm (x 1)
by default 67.5 mm (x 1.5)
• The Z-axis is approx. twice as fast 90 mm (x 2)
as previous Mahr Z-axes 112.5 mm (x 2.5)
• Up to 5 times faster than 135 mm (x 3)
standard Z-axes on the market
• Contacting and zeroing via the APPLICATIONS ACCESSORIES
Z-axis
Mechanical Engineering Optional
New flexible probe system • Bearings, threads, threaded bars, ball screws, • Manual control panel with joystick and display
mount with BFW probe system shafts, racks • Motor-driven TY axis
• Simple probe arm change and • Parallel vice
probe arm protection by means Production metrology • Prism block
of magnetic probe arm holder • Contour measurement in a semi-automatic process • Equipment table
• Probe arm holder allows the • Vibration damping system
change from standard to Automotive industry
transverse measurement without • Steering, brake system, gearbox, crankshaft, General software options
tools or adapters camshaft, cylinder head • Option - RoughnessPLus
• Extensions for the touch probe • Option - MeasurementPlus
are possible Medical technology • Option - Dominant Waviness (WDc) for MarWin
• Contour of hip and knee endoprosthesis, contour of • Option - ISO 13565-3 surface parameters
Innovative workpiece clamping medical screws, contour of dental implants • Option - QS-STAT / QS-STAT Plus
system • Option - Profile processing
• Mounting plate 390 x 430 mm • Option - User-defined parameters
with bore dimension 50 mm • Option - Topography
• Integrated 60 mm TY adjustment
• The combination of mounting
plate and integrated TY adjust-
ment makes an additional XY
table superfluous
• Low workpiece setup supports a
favorable short measurement
loop, which has a positive effect
on the measurement results
