RATCHET RING WRENCH SET, RATCHETING SPANNER HEAD No need for inserting and removing wrench, possible for fast turning.
Recommended for work at confined spaces since the straight and
thin body.
Models RMQ700 Ideal for tightening work in piping flare nuts and confined places.

Contents 7 Items Good Design award winning item
Models RMQ- 08 10 12 13 14 17 19 Quick type (Straight body)
Across Flat(mm) 8 10 12 13 14 17 19
● Tool bag (BNRM7L)
● Weight : 0.96kg
● Qty./Carton : 1
※ A tool bag is available for separate purchase. Please see P115.
Easy to store and carry!!

RMQ700

RATCHET RING WRENCH, RATCHETING SPANNER HEAD Good Design award

Across Dimensions (mm) Qty./Carton Weight
Models Flat RMQ-08
(mm) (g)
D1 D2 T1 T2 L (Generally) (Store Center)
RMQ-08 8 16.2 16.4 4.1 6.5 140 10 10 30
RMQ-10 10 20.5 20.0 4.8 7.3 158 10 10 50
RMQ-12 12 24.6 22.6 5.3 8.2 171 10 10 70 RMQ-17
RMQ-13 13 26.7 24.5 5.9 8.6 178 10 10 80
RMQ-14 14 28.8 27.0 6.3 9.0 190 10 10 105
RMQ-17 17 35.1 31.6 7.3 10.3 225 10 10 165
RMQ-19 19 39.3 33.7 8.3 11.2 247 10 10 210
5IF XSFODI QBSU

" TQFDJBM IFBE EFTJHO BMMPXT VTFS
" TQFDJBM IFBE EFTJHO BMMPXT VTFS
UP XPSL TNPPUIMZ XJUIPVU IBWJOH
UP XPSL TNPPUIMZ XJUIPVU IBWJOH
UP SFNPWF BOE SFJOTFSU UIF XSFODI
UP SFNPWF BOE SFJOTFSU UIF XSFODI
Product video

CAUTION
●

Example

How to use the wrench part How to use the glasses part
Insert Tighten Turn Insert Tighten Turn Tighten

Access bolt/nut Contact by 4 faces The part of the wrench part slides, and without
and maintain bolt nut surely. removing it, continuous work is possible.
Repeat Repeat

CAUTION ● Use wrench suitably fitted with bolt / nut.
● Do not use with extension pipe etc. 327
● Avoid giving shock by hitting with hammer etc.
