Page 327 - 日本前田TONE

RATCHET RING WRENCH SET, REVERSIBLE OFFSET Easy to switch reverse and forward direction with finger.
Matt fininshed, thin ratchet head.

Models RMR700 Good Design award winning item
13° offset type
Contents 7 Items
Models RMR- 08 10 12 13 14 17 19
Across Flat(mm) 8 10 12 13 14 17 19
● Tool bag (BNRM7L)
● Weight : 0.94kg ● Qty./Carton : 1
※ It is changed into the one with stop mechanism at any time.
※ A tool bag is available for separate purchase. Please see P115.

Easy to store and carry!!

RMR700

Models RMR110 Ratachet ring wrenches from Next Generation series is set in a
new style metal case.
Contents 11 Items Good Design award winning item
Models RMR- 08 10 12 13 14 15 16 17 18 19 21
Across Flat(mm) 8 10 12 13 14 15 16 17 18 19 21
● Tool case : MCT2
● Package size : w406 x d120 x h60mm
● Weight : 2.6kg ● Qty./Carton : 1
※ It is changed into the one with stop mechanism at any time.

RATCHET RING WRENCH, REVERSIBLE OFFSET
RMR110

Across Dimensions (mm) Qty./Carton Weight
Models Flat
(mm) (g)
D1 D2 T1 T2 L (Generally) (Store Center) Good Design award
RMR-08 8 16.7 16.6 4.6 6.5 140 10 10 30
RMR-10 10 20.8 20.0 5.3 7.3 159 10 10 50
RMR-12 12 25.0 22.7 6.0 8.2 172 10 10 70 RMR-08
RMR-13 13 27.1 24.7 6.4 8.6 178 10 10 85
RMR-14 14 29.2 27.0 6.8 9.0 191 10 10 100 RMR-17
RMR-15 15 31.3 28.3 7.0 9.4 200 10 10 120
RMR-16 16 33.4 30.0 7.2 9.9 208 10 10 140
RMR-17 17 35.5 31.8 7.7 10.3 226 10 10 170 $8 $$8 TXJUDIBCMF $IBOHF MFWFS &BTZ UP VTF XJUI P⒎TFU
RMR-18 18 37.6 32.6 8.2 10.7 237 10 10 195
RMR-19 19 39.7 33.8 8.8 11.2 248 10 10 215
RMR-21 21 46.0 40.0 9.0 13.0 290 10 10 340
RMR-22 22 46.0 40.0 9.0 13.0 290 10 10 365
RMR-24 24 52.2 46.0 10.0 14.5 323 10 10 495 $8 $$8 TXJUDIBCMF $IBOHF MFWFS &BTZ UP VTF XJUI P⒎TFU
※ It is changed into the one with stop mechanism at any time.

TOOL CASE (METAL)

Stopper function
Models MCT1, MCT2, MCT3
8IFO GPSDFE
Turn to P113 for 8IFO TUPQT
more information.
MCT1 MCT2 MCT3
Product video

CAUTION ● Switch over the direction completely.
● Use wrench suitably fitted with bolt / nut.
● Do not use with extension pipe etc. 325
● Avoid giving shock by hitting with hammer etc.
