2 sizes in 1 wrench, both sides with ratchet mechanism. Both RATCHET RING WRENCH, FLEX HEAD SET
sides can be adjusted with 15°. Possible for working in confined
spaces. Hanging hole for the fall prevention cable (RMFW-1214
and larger size). Models RMFW500
Good Design award winning item Contents 5 Items
Double flex head ratchet type Models RMFW- 0810 1113 1214 1618 1719
Across Flat（mm） 8×10 11×13 12×14 16×18 17×19
● Tool bag (BNRM7L)
● Weight : 1.08kg
● Qty./Carton : 1
※ Tool bag (2 spare pockets).
※ A tool bag is available for separate purchase. Please see P115.
※ In case of out-of-stock, non-locking flex head will be automatically changed to locking flex
head (15˚ angle each turn).
Easy to store and carry!! Example

RMFW500

Good Design award RATCHET RING WRENCH, FLEX HEAD

Across Dimensions (mm) Qty./Carton Weight
Models Flat
(mm) (g)
D1 D2 T1 T2 L (Generally) (Store Center)
RMFW-0810 8×10 16.4 20.0 6.5 7.3 151 10 10 60
RMFW-1214 RMFW-1012 10 × 12 20.0 23.0 7.3 8.2 176 10 10 93
RMFW-1113 11 × 13 21.8 25.2 7.7 8.6 197 10 10 120
RMFW-1214 12 × 14 23.0 26.8 8.2 9.0 199 10 10 129
RMFW-1314 13 × 14 25.2 26.8 8.6 9.0 204 10 10 138
RMFW-1317 13 × 17 25.2 31.8 8.6 10.3 229 10 10 187
RMFW-1417 14 × 17 26.8 31.6 9.0 10.3 230 10 10 187
RMFW-1719 RMFW-1618 16 × 18 29.8 32.8 9.9 10.7 263 10 10 258
RMFW-1719 17 × 19 31.8 33.9 10.3 11.2 267 10 10 271
● With safety rope attaching hole (RMFW-1214 and larger)
※ In case of out-of-stock, non-locking flex head will be automatically changed to
locking flex head (15˚ angle each turn).
'MFY IFBE
A safe rope installation example .PTU TVJUBCMF GPS UJHIU TQBDF

'MFY IFBE .PTU TVJUBCMF GPS UJHIU TQBDF

CAUTION ● Use wrench suitably fitted with bolt / nut.
330 ● Do not use with extension pipe etc.
● Avoid giving shock by hitting with hammer etc.
