Head can be fixed with 15°, best tool for work in where no tools RATCHET RING WRENCH SET, FLEX HEAD
can reach so far.
Matt fininshed, thin ratchet head.
Hanging hole for the fall prevention cable (RMF-14 and larger size). Models RMF700
Good Design award winning item Contents 7 Items
Standard flex head ratchet type. Models RMF- 08 10 12 13 14 17 19
Across Flat(mm) 8 10 12 13 14 17 19
● Tool bag (BNRM7L)
● Weight : 1.02kg
● Qty./Carton : 1
※ A tool bag is available for separate purchase. Please see P115.
※ It is changed into the one with 15° angle arrangement mechanism.

Easy to store and carry!!

RMF700

A ratchet wrench of glasses of "next generation tool series" is set Models RMF100
in a metal case.
Good Design award winning item Contents 10 Items
Models RMF- 08 10 12 13 14 15 16 17 18 19
Across Flat(mm) 8 10 12 13 14 15 16 17 18 19
● Tool case : MCT2
● Package size : w406 x d120 x h60mm
● Weight : 2.4kg ● Qty./Carton : 6
※ It is changed into the one with 15° angle arrangement mechanism.
RMF100
RATCHET RING WRENCH, FLEX HEAD

Good Design award
RMF-08
Models Across Dimensions (mm) Qty./Carton Weight
Flat
(mm) (g)
D1 D2 T1 T2 L (Generally) (Store Center)
RMF-07 7 16.2 16.7 4.3 6.5 127 10 10 36
RMF-08 8 16.2 16.7 4.3 6.5 127 10 10 35
RMF-17
RMF-10 10 20.3 20.0 5.0 7.3 136 10 10 55
RMF-11 11 22.5 21.8 5.4 7.7 141 10 10 65
RMF-12 12 24.3 23.0 5.8 8.2 148 10 10 75
'MFY IFBE
A safe rope installation example .PTU TVJUBCMF GPS UJHIU TQBDF RMF-13 13 26.8 25.2 6.1 8.6 154 10 10 90
RMF-14 14 28.7 26.8 6.4 9.0 160 10 10 110
RMF-15 15 30.5 28.3 6.9 9.4 169 10 10 125
RMF-16 16 32.9 29.8 7.2 9.9 179 10 10 150
RMF-17
'MFY IFBE .PTU TVJUBCMF GPS UJHIU TQBDF 17 34.5 31.8 7.6 10.3 190 10 10 170
RMF-18 18 37.0 32.8 8.0 10.7 203 10 10 195
RMF-19 19 39.2 33.9 8.6 11.2 215 10 10 220
RMF-21 21 46.0 40.0 9.0 13.0 274 10 10 400
RMF-22 22 46.0 40.0 9.0 13.0 274 10 10 390
TOOL CASE (METAL) RMF-24 24 52.2 46.0 10.0 14.5 296 10 10 540
● With safety rope attaching hole -
Models MCT1, MCT2, MCT3 (RMF-14 and larger)
Turn to P113 for
more information.
MCT1 MCT2 MCT3

CAUTION ● Use wrench suitably fitted with bolt / nut.
326 ● Do not use with extension pipe etc.
● Avoid giving shock by hitting with hammer etc.
