MECHANIC OFFSET WRENCH SET, LONG TYPE (45°×10°) Long offset wrench (45˚) with low-angle head design (10˚) allows
working in confined space even with obstacles.
The ring head allows force to separate equally and makes bolt/nut
Models M446 difficult to slip off even when using heavy force.
Long offset wrench set (45˚x10˚) that comes with satin-finish tray
Contents 6 Items and a metal case.
Models M44- 0810 1012 1214 1417 1921 2224
Across Flat(mm) 8×10 10 × 12 12 × 14 14 × 17 19 × 21 22 × 24
● Tool case : MCT2
● Tray : TCB027
● Package size : w406 x d120 x h60mm
● Weight : 2.1kg ● Qty./Carton : 6

MECHANIC OFFSET WRENCH, LONG TYPE (45°×10°)

M446
Across Dimensions (mm) Qty./Carton Weight
Models Flat
(mm) (g)
D1 D2 T1 T2 L (Generally) (Store Center)
M44-5.507 5.5× 7 10.0 11.5 5.0 5.5 151 10 10 30
M44-0810 8×10 13.0 15.5 6.0 6.5 184 10 10 50
M44-1012 10×12 15.5 18.0 6.5 7.5 194 10 10 70
M44-1013 10×13 15.5 19.0 6.5 8.0 196 10 10 65
M44-1113 11×13 16.5 19.0 7.0 8.0 198 10 10 70 M44-1214
M44-1214 12×14 18.0 21.0 7.5 8.5 219 10 10 110
M44-1317 13×17 19.0 25.0 8.0 9.5 247 10 10 130 M44-1921
M44-1417 14×17 21.0 25.0 8.5 9.5 248 10 10 140
M44-1719 17×19 25.0 27.5 9.5 10.5 279 10 10 195
M44-1921 19×21 27.5 29.5 10.5 11.5 306 10 10 260
M44-2224 22×24 31.5 34.5 12.0 13.5 323 10 10 310
M44-2427 24×27 34.5 37.5 13.5 15.0 350 10 10 420

OFFSET WRENCH SET, SHORT TYPE (45° ) With 45˚ offset and short body, making it possible to work in a
confined space with obstacles.
Models M465

Contents 5 Items
Models M46- 0809 1012 1113 1214 1417
Across Flat(mm) 8×9 10 × 12 11 × 13 12 × 14 14 × 17
● Packaged in a plastic case.
● Weight : 0.25kg ● Qty./Carton : 1
OFFSET WRENCH, SHORT TYPE (45° ) M465

Across Dimensions (mm) Qty./Carton Weight
Models Flat
(mm) D1 D2 T1 T2 L (Generally) (Store Center) (g)
M46-5.507 5.5× 7 10.0 11.5 5.0 5.5 104 10 10 20 M46-1012
M46-0809 8× 9 13.0 14.5 5.5 6.0 105 10 10 20
M46-0810 8×10 13.0 15.5 5.5 6.5 108 10 10 20
M46-1012 10×12 15.5 18.0 6.5 7.5 115 10 10 35
M46-1113 11×13 16.5 19.0 7.0 7.5 115 10 10 40
M46-1214 12×14 18.0 21.0 7.5 8.5 130 10 10 55
M46-1417 14×17 21.0 25.5 8.5 9.5 147 10 10 80 M46-1921
M46-1921 19×21 28.0 30.0 10.5 11.5 175 10 10 150

TOOL CASE (METAL)

Models MCT1, MCT2, MCT3
Turn to P113 for more information.

MCT1 MCT2 MCT3

CAUTION
● Use wrench suitably fitted with bolt / nut. 321
● Avoid giving shock by hitting with hammer etc.
