Ideal for the work with height restriction since the handle's OFFSET WRENCH SET, LONG TYPE (15° )
turning angle is 15 °.
New metal case with matt finished tray.
Models M156

Contents 6 Items
Models M15- 1012 1113 1214 1417 1921 2224
Across Flat(mm) 10 × 12 11 × 13 12 × 14 14 × 17 19 × 21 22 × 24
● Tool case : MCT2
● Tray : TCB028
● Package size : w406 x d120 x h60mm
M156 ● Weight : 2.1kg ● Qty./Carton : 6
)
OFFSET WRENCH, LONG TYPE (15°

Across Dimensions (mm) Qty./Carton Weight
Models Flat
(mm) (g)
D1 D2 T1 T2 L (Generally) (Store Center)
M15-1012 10×12 15.5 18.0 6.5 7.5 192 10 10 60
M15-1113 11×13 16.5 19.0 7.0 8.0 193 10 10 60
M15-1214 12×14 18.0 21.0 7.5 8.5 224 10 10 95
M15-1214 M15-1417 14×17 21.0 25.5 8.5 9.5 253 10 10 140
M15-1921 19×21 28.0 30.0 10.5 11.5 328 10 10 220
M15-2224 22×24 32.0 35.0 12.0 13.5 334 10 10 290

M15-1921

Ideal for work in confined and deep spaces with height RING WRENCH, LONG TYPE
restrictions.
Tighten and loosen with a small force since it's long.
Bi-hex, easy to slide the wrench into the receiving slot. Across Dimensions (mm) Qty./Carton
Models Flat Weight
(mm) (g)
D1 D2 T1 T2 L (Generally) (Store Center)
M05-0810 8×10 13.5 16.0 7.5 8.0 235 10 10 60
M05-1012 10×12 16.0 18.5 8.5 9.0 295 10 10 110
M05-1012 M05-1113 11×13 17.0 19.0 9.0 9.5 310 10 10 130
M05-1214 12×14 18.5 21.0 9.5 10.0 330 10 10 170
M05-1315 13×15 19.0 23.0 9.5 11.0 350 10 10 180
M05-1417 14×17 21.0 25.5 11.0 12.0 370 10 10 200
M05-1214 M05-1618 16×18 24.5 27.0 11.5 13.0 390 10 10 220
M05-1719 17×19 25.5 28.0 12.5 13.5 405 10 10 340
M05-1921 19×21 28.5 31.0 13.5 15.0 420 10 10 520
Example M05-2224 22×24 32.0 35.0 15.0 16.0 435 10 10 570
M05-1719
M05-2730 27×30 39.0 43.0 19.5 22.0 500 5 5 960
M05-3236 32×36 47.0 53.0 23.0 24.0 550 5 5 1,420

TOOL CASE (METAL)

Models MCT1, MCT2, MCT3
Turn to P113 for more information.

MCT1 MCT2 MCT3

CAUTION
322 ● Use wrench suitably fitted with bolt / nut.
● Avoid giving shock by hitting with hammer etc.
