CIRCUIT TESTERS
ELECTRONICS

Specifications EECT900
AC Measurement TRMS, V AC 200
AC Measurement P-P, Volts 200
Amp Measurement Range, Amps .5–50
CE Approved Yes
Circuit Breaker Range, Amps 2–30
DC Percentage Measurement Range 1–99
DC Measurement Range, Volts .5–200
Display Size, Inches 2.4
Amperage AC V
Hz Measurement Range 15–9,999
Max. Continuous Load, Amps 12
Max. Intermittent Load, Amps/30 29
Seconds
Max. Operating Tempurature, °F (°C) 123 (50)
Max. Operating Voltage, V DC 34
Max. Storage Temperature, °F (°C) 158 (70)
EECT900
Max. Tip Voltage 200
Max. Transient Voltage, Volts per
Second 550
Digital Display Circuit Testers DC V Ohms V DC, Ohms, Amps, V
Meter Modes AC (Freq, TRMS, DC
EECT900 Multi-Probe Ultra Percentage, P-P, PW)
Capability Min. Operating Temperature, °F (°C) 14 (-10)
• Tests AC and DC voltage, resistance (ohms) and amperage in Min. Operating Voltage, V DC 9
vehicle applications Min. Storage Temperature, °F (°C) 4 (-20)
• Patented circuit breaker-protected power-up of components to
determine function Normal Battery Voltage Range, V DC 12–24
& • Built-in vehicle battery status check provides information to the Only), Ohms 0.1–50,000
Ohm Measurement (Continuity
technician before proceeding with circuit diagnosis (may need to
7154899
Patent Number
charge the battery)
23 (7.01)
Accessibility Power Cable Length, Feet (Meters) Momentary, Latch,
14
• Ergonomic hand-hold position and large rear-facing color LCD
Power Cable Gauge
TESTING • Provides audible smart-tones to indicate tip readings, warning Product is designed to be powered by 12 –24 VDC power sources such as
display lets the user get in tight spaces and still read the live
Power Switch Modes
Pulse
results on the screen
• Convenient 23ʹ cable allows the user to connect to the vehicle
PW Measurement Range, mS
0.05–1000
battery and move around the vehicle, including trucks, to check
Batt Stat, Hot Shot
Special Tests
distant circuits like brake lights or trailer terminal connections
found in Automotive, Truck, Small Craft Marine, and Small Craft Aviation
electrical systems
sounds and more
• Unit is not intended to be connected to 110 AC or above wall outlets
Simplicity
• Do not supply battery voltage to any computerized circuits, sensors, air
• Navigation is simplified via a color-coded menu—five menu
bag or supplemental restraint systems
NOTE: Due to the OHM meter capability, an extension cable cannot be
selections are identified with a unique color so the user recalls the
used, it will negatively impact the accuracy of the readings
mode in use: Purple = AC Voltage, Orange = DC Voltage, Yellow =
Amperage, White = Ohms
• Single-function buttons are used for up and down scrolling, clear,
menu/mode toggle, mute, light on/off and +/- powering of a circuit
• Inclusive AC meter displays all measurements simultaneously—
• Optional carrying case
Peak to Peak, Pulse Width, Duty Cycle, Frequency and TRMS
Cable
EECT900-1 23ʹ Cable
Serviceability
• 23ʹ cable for EECT900
• 23ʹ cable is field replaceable and calibrated—saves the time of
EECT900-2 Battery Clamps
sending a complete unit in for repair if just the cable fails EECS550-CC Carry Case Field Replaceable
• 18 month warranty • Battery clamps for EECT900
• Technical Support: 888-549-0566 EECT900-5 Tungsten Probe Tip, 3-1/2ʺ Length
• Optional 3.5 mm tungsten probe tip for EECT900
EECT900-6 Brass Probe Tip, 3-1/2ʺ Length
• 3.5 mm brass probe tip for EECT900
EECT900-9 Ground Cip with Boot
EECT900-11
• Ground clip with boot for EECT900
EECT900-10 5 V Multi-Probe Adaptor
®
(Blue-Point )
• Tip adaptor quickly connects between the
tool and the probe tip to provide a safe 5 V
reference signal to sensors, components
and circuits
EECS550-CC EECT900-1 EECT900-2
• Replaces missing ECM 5 V reference
• Safely power and tests low voltage components
• Identifies shorted sensors and circuits
EECT900-11 Brass Probe Tip, 6ʺ Length
• 6ʺ brass probe tip for EECT900
612 EECT900-5 EECT900-6 EECT900-9 EECT900-10
