TEST LEADS
ELECTRONICS

Retractable Test Leads
®
YA1175KIT ‡ Retractable Test Lead Kit (Blue-Point )
• Includes YA1175
• Retractable test leads, YA1175-1 Probes (pair), YA1175-2 Alligator
Clips (pair) and YA1175-3 Spring Hooks (pair)
YA1175-1
• Retractable test leads pull out and stay at desired length
• Rewind test leads when not in use for compact storage
• 18-gauge copper wire and interchangeable tips
YA1175-1 ‡ Probes (Blue-Point )
®
YA1175KIT • Pair of probes for the YA1175 Retractable Test Lead
YA1175-2 Alligator Clips (Blue-Point )
®
• Pair of alligator clips for the YA1175 Retractable Test Lead
®
YA1175-3 Spring Hooks (Blue-Point )
YA1175-3
• Pair of spring hooks for the YA1175 Retractable Test Lead
YA1175-2
Back Probes
MTTL7005PK Back Probes
• Color coded for easy identification
• Bendable stainless steel tips (standard diameter)
• Non-intrusive probes slide behind the terminals
• Modular ends slide quickly into the modular test leads for fast and
reliable connections or use with MTTL7002 with threaded test leads
• Each probe is 4-1/2ʺ (11.5 cm) long with a tip diameter of 1/32ʺ (1 mm)
• Removable boots enable custom color selections or restoring color
to dirty used boots with the MTTLBOOTS Multi-Pack
& MTTL7005PK MTTL7006 MTTL7005 Back Probe Adaptors—(1) Red, (1) Black
MTTL7006 Micro Tip Back Probes
• Feature a 0.5 mm diameter tip that has enough muscle to probe
new smaller vehicle interior compartment connector terminals
TESTING MTTL502 • 4 mm standard female banana jack ®
• Modular test lead ends for quick attachment or use with MTTL7002
and threaded test leads
• Replaceable threaded tips make change-outs easy
MTTLBOOTS
• 4ʺ overall length
• Rated to 60 V DC
MTTLBOOTS Replacement Boot Kit
• Five of each black, red, yellow, green, blue
MTTL502 Test Probes
• Use probes on threaded probe tips
• Includes banana adaptors so probes can be used on banana plug
lead sets
MTTL720 20 pc Back Probe Pin Kit (Blue-Point )
• Just slip the probing pin into the backside of the electrical
connector and attach the meter lead to the alligator clip at opposite
end of the pin
• Five colors (black, red, yellow, green, blue) make circuit
identification easy
• Insulated boots protect the circuit being tested from shorting
between circuits and/or a short circuit to ground
MTTL720
• Probing pin can be bent to access an electrical connector at an
unusual angle for awkward connections
MTTLB720 20 pc Multi-Back Probe Pin Kit (Blue-Point )
®
• Includes five of each: 45° sharp, 45° blunt, 90° sharp and
straight sharp
MTTL7007 Insulated Back Probe Set
• Designed to slide between the weather protective terminal seals
on vehicles for easy probing
• Slide-on terminals for easy-on positioning on threaded or straight
MTTLB720 metal prods
• 4ʺ overall length with shaft length of 2ʺ for good reach
• 300 volts DC, 3 amps DC rating for many applications
• CAT II 300 V DC safety rating
• Internal collar diameter: 11 mm
• Internal female diameter: 2 mm
MTTL7007
