CIRCUIT TESTERS

EECT424HD TESTING
Digital Display Circuit Testers Specifications EECT424HD
Voltage 24
EECT424HD 24 V Digital Display Circuit Tester Range 4.0–49.9 V DC
(4–49 V DC Range) Resolution 0.1 V DC
• Used to detect voltage, power, ground and circuit integrity
on cars and trucks Accuracy ± 0.3 Volt &
• LCD display provides a “no guess" voltage value Cord Color Red
of the circuit Cord Type Straight/Polyurethane
• LEDs indicate Green for Ground or Red for Power Outside Wire Diameter, .16 (4)
• Leaves one hand free to jiggle wires, replace a fuse or inches (mm)
operate a switch Cord Length, ft (m) – gauge 6 (2) – 18
• Surge-protected circuitry displays 4–49.9 V DC Replacement Cord Assembly EECTCORD424V
(± 0.3 V accuracy) Replacement LED and Spring EECT424LCD
• Computer safe <10 mA circuit draw for confident testing Assembly
• 3-1/2ʺ stainless steel corrosion-free shank Handle Size/Color Instinct /Clear w/Red Print
®
• Patented Instinct clear handle for pure visibility, Display LCD w/Backlight
®
style and comfort Bi-Directional with Color LED, Red
• Solid-copper clip—superior quality component for Polarity and Green indicators
maximum electrical signal transfer Surge Protected Surge and high DC voltage
• Superior flex wire glides past components and remains Operating Temperature 0–120 °F (-18–50 °C)
flexible in cold conditions Terminal End Heavy-Duty Copper Clip
• Convenient field-replaceable digital display board and Replacement Clip EECTCLIPHD-R
spring assembly
Stainless Steel Shank Length, ELECTRONICS
inches (cm) 3-1/2 (8.9)
Length, inches (cm) 8-1/4 (20.9)
Warranty 1 Year (field repairable)
Computer Safe Yes <10 mA (not for use on airbags)

Cord-Free Circuit Testers
• For quick detection of DC voltage
• For use on autos and trucks from 3–24 V DC
• Probe the wire and touch metal ground on the vehicle with a free hand
• Black carbon-infused contact area completes the circuit EECT200
®
• Mini Instinct handle and short stainless shank for tight access jobs
• Pocket clip to keep the first need diagnostic tool ready for work
• Safety tip-protector
• Do not use on airbags or AC voltage
EECT200 Cordless DC Circuit Tester
• Audible beep and bright white LED light alerts the user
to DC voltage presence
EECT201BL Cord-Free Pocket DC Circuit Tester
• Vibration, audible beep and bright LED light alerts the
user to DC voltage presence EECT201BL

613
• Do not use in environment with explosive vapor
• Read safety precautions on pages W1 to W4
