CIRCUIT TESTERS

Storage Racks
• Three heavy-duty magnets for quick attachment and mobility
• Stores inside the door of tool storage lockers for security at night
• Both racks can be mounted to the wall with screws or placed on a
roll cab with a magnetic back EEDMRACKBJR
• Ideal for use on the side of a toolbox or service cart
• Attaches to any flat metal surface TESTING
EEDMRACKBJR DMM Banana Jack Storage Rack
• Convenient rack with banana jacks to hold test leads, back
probes, adaptors and more
EEDMRACKM Multi-Purpose Magnetic Tool Storage Hanger
EEDMRACKM

Specialty Circuit Tester
®
EECT74 Amp Hound (Blue-Point )
• For use on 6, 12 and 24 V electrical systems
• No need to remove a fuse, reducing the amount of time to &
determine the current in the circuit
• Finds parasitic drains without resetting the offending circuit
• Checks the fuse box quickly without repeatedly pulling a fuse
and checking the meter
• Will not short a circuit while the fuse is removed
• Touch the probes to the top of the fuse EECT74
• Tests all of the most common types of automotive fuses
and amp ranges
• Intelligent audible tones and digital displays
• Active circuit unit beeps three times and displays the amp value
• Inactive circuit beeps continuously and displays (000)
• Open or blown fuse will not beep and displays (-—-)
EECT72 ‡ Amp Hound 2 (Blue-Point )
®
• Same as the EECT74 with additional features
• Real-time readings
• Plug-in fuse adaptors
• Functions with micro fuses ELECTRONICS
EECT72
Dynamic Test Leads
®
®
EECT180 LOADpro Dynamic Test Leads (Blue-Point )
®
• LOADpro quickly finds problems like high-corrosive resistance,
shorts to ground and open circuits
• Works with any DMM with standard banana plugs
• Test leads are 60ʺ in length
• For use on circuits up to 28.5 V
• Do not use on computer ECM input circuits
®
• LOADpro performs a voltage drop test with the press of a button
• Steady pin probe tips—a small recess allows the probe to sit on
the connector pin
• Pressing the switch applies a load of 40 mA per volt across the
circuit (example: 40 mA x 12 V = .48 A of load)
• Used for automotive, heavy-duty, marine, RV and equipment EECT180
• Includes the ESI182 Troubleshooting Guide
OBD-II Breakout Boxes
®
YA11167 OBD-II Breakout Box (Blue-Point )
• Provides easy access to all 16 OBD-II terminals
• Eliminates guessing which terminals are being probed
• Eliminates damage to vehicle terminals from probing
• Tester probes plug in securely so the technician is free to diagnose
• No more crawling under the dash
• Great for diagnosing inoperative communication links
YA11167

• Do not use in environment with explosive vapor 617
• ‡ These products can expose you to chemicals which are known to the state of California
to cause cancer and reproductive harm. See pages 906-907 for details.
• Read safety precautions on pages W1 to W4
