CIRCUIT TESTERS

Short-Circuit Locators
YA111KITA Relay Shorting Plug Kit YA111-10A Relay Shorting Plug
®
®
(Blue-Point ) (Blue-Point )
• Plugs close normally open contacts • 10 A
and instantly determine which half of YA111-15A Relay Shorting Plug
an output circuit is suspect (Blue-Point ) TESTING
®
• Eliminate guessing which terminals • 15 A YA111KITA
to short
• Significantly reduce diagnostic time YA111-20A Relay Shorting Plug
®
• Kit works on all vehicles using (Blue-Point )
standard four- and five-pin relays • 20 A
• Avoids damage to the relay socket as
a result of probing
Continuity Testers
®
®
EEFB310 Fuse Buddy Pro Test Kit (Blue-Point ) &
• Great tool for reading circuit amperage draws and
troubleshooting up to 30 A
• Includes (1) meter with (3) interchangeable test
functions: 30 A MINI circuit current testing,
30 A ATC circuit current testing and 30A all-purpose
current testing
• Plugs directly into MINI and ATC fuse sockets
• Original fuse is replaced in-line, maintaining
circuit protection
• Measuring range: 0–30 A/48 V DC 10 seconds
• Accuracy: ±2% of reading
• Resolution: 100 mA
EEFB310-1 Replacement Fuse Buddy Pro Meter
®
(Blue-Point )
®
®
EEFB310-2 Fuse Buddy Pro ATC Adaptor Set
®
EEFB310-3 Fuse Buddy Pro ATC Fuse Adaptor Set EEFB310 ELECTRONICS
EEFB310-4 Fuse Buddy Pro Positive/Negative Clamp
®
Adaptor Set
®
®
EEFB315 Max Fuse Buddy Kit (Blue-Point )
• MAXI circuit testing capability up to 80 A
• Works with MINI and ATC circuits (adaptors included)
• Unit features peak hold functions and one-touch
zero function
• Use on antilock brake circuits, car stereo circuits, power
distribution circuits, marine and automotive branch
circuits, rear window defogger circuits, solar power DC
branch circuits, traction control circuits, solar charge
controller circuits and heavy-duty equipment circuits
• Amps: 0–80A DC
• Resolution: 0.1A
• Accuracy: ±2.0% of reading + four digits
EEFB315-1 ATC Fuse Adaptor for Max Fuse Buddy
®
®
(Blue-Point )
EEFB315-2 Mini Fuse Adaptor for Max Fuse Buddy
®
(Blue-Point )
®
EEFB315
