ELECTRONICS LEAK DETECTORS

Diagnostic Smoke Machine

Specifications EELD100A†
Power Supply 12 V DC
Power Consumption 12 V DC, 25 A
Supply Volume 10 L/MIN
Line Length/Smoke Supply, ft (m) 8 (2.44)
Line Length/Power Supply, ft (m) 8 (2.44)
Line Length/Remote Starter, ft (m) 10 (3)
Max. Pressure Input 170 PSI
12 W x 13 D x 12 H
Overall Dimensions, inches (mm) (305 W x 229 D x 305 H)
Weight, lb (kg) 11.5 (5.25)
†
Included Accessories:
®
EELD100-4 Combo Light (Blue-Point )
EELD100A-3 Smoke Hose Extension with Delrin Nozzle
®
EELD100A EELD100A-4 Tee Connector with Delrin Nozzle
®
EELD301A2 17 pc Cap Plug Kit
®
EELD100A Diagnostic Smoke Machine (EVAP) EELD301A3 Exhaust Cone Adaptor
• Finds leaks EELD301A4 Wind/Water Leak Adaptor
®
• Contains Diagnostic Smoke technology for EVAP EELD302A1 Nitrogen Hose
testing and general-purpose applications EELD302A2 EVAP Service Port Adaptor Standard Size
®
• UltraTraceUV non-contaminating dye solution EELD302A3 EVAP Service Port Adaptor Fitting
pinpoints leaks that smoke cannot locate alone
• Includes a combination LED and UV light, EELD302A4 Schrader Valve Core Tool
& • Necessity—Eight of the top 10 emission DTC codes can
plus special glasses
be diagnosed with this unit
EELDCAPLESS
• Smoke solution does not produce an unpleasant odor EELDCAPLESS Capless Fuel Tank Adaptor
TESTING • Convenient retractable hanger for under car and under • EVAP testing is simplified through a dual-door fill neck;
in the shop
• Variable flow control manually reduces the flow to help
pinpoint the exact location of a leak
• Specifically designed for new capless fuel tank
• Conveniently functions with OEM-specified optional
filler necks
nitrogen, a portable CO2 bottle (ships empty) or shop air
no need to tap into EVAP system
• For use with EELD500 or EELD100A smoke machines
hood use
(sold separately)
• Lightweight and compact stores in a large bottom roll
cab drawer or hangs with an optional cover to protect
• Seals both doors with a simple twist of the perforated
from shop dirt
knob to expand the bladder for accurate testing
®
Evaporative Emissions Diagnostic Smoke Vapor Producing Machines – Feature Comparison
EELD500
EELD100A
Uses Diagnostic Smoke vapor technology developed in collaboration with Ford Motor Co., GM , Daimler Chrysler and
®
approved by most major OEMs.
Non-contaminating UltraTraceUV dye solution pinpoints the leak. The only dye solution mandated by most major OEM's.
•
•
Will not harm activated charcoal canister, ORVR valve, purge valves, catalytic converters, O 2 sensors, seals or gaskets and
determined not to void vehicle factory warranty.
•
•
Technology meets specifications when OEMs require nitrogen for safer EVAP system testing. ® ® • •
Designed with an electronic Safety Valve that automatically shuts off air flow into the vehicle's EVAP system when
the machine turns off. This stops gasoline fumes from exiting the EVAP system and filling your work bay. • •
TECH LINE Supported 1-800-901-1988 for end user to help with any and all EVAP problems. • •
Vacuum/Pressure Gauge for vacuum/pressure decay. • •
Convenient Hook with fold down handle for hanging under car or under hood and easy storage in tool box. • •
Ability to read and display leak size of .010". • •
10-Year Warranty On Glow Plug a reliable heating system that lasts much longer than fiberglass wick-style units. • •
Variable Flow Control manually reduces flow to help pinpoint the exact location of a leak. •
Low Flow Pulsating Mode automatically adjusts flow to optimal setting to help find small leaks. •
One-Touch EVAP Testing with automatic pass or fail. •
Vacuum Port Adapter can apply hand vacuum pump for testing Fuel tank Pressure Sensors, Chrysler ESIM & NVLD systems.
Also gives you dual smoke hose capability. •
Computerized Digital Display down to .001" means you’re prepared for any industry leak standard changes. •
Computerized Digital Display Reading Flow in Liters per Minute to make sure factory specs are met. •
Computerized Digital Display Reading Pressure/Vacuum in H 2O to compare to FTP Sensor for in-depth diagnostic ability. •
Sleep Mode with Memory retains test results if machine shuts down after five minutes. •
Cordless remote so there is no need to walk back and forth when doing a job. •
Micro-processor touch pad for quick and easy operation. •
Ability to Choose Inert Gas at start-up for 100% accurate results. •
