CIRCUIT TESTERS
ELECTRONICS

EEDMCT-KIT Digital Multimeter, Circuit Tester
and “Y” Terminal Master Kit
• Bring the all-in-one kit to the job for 12 and 24 V auto
and truck electrical testing
• Includes the EEDM504D, EECT413 and MTTL900-KIT sets
in one complete diagnostic package
• The circuit tester is used with various non-intrusive probes
and adaptors for quick testing
• Our most popular digital multimeter includes the addition of
resistance, AC and DC voltage testing, and more
• Unique “Y” adaptor enables testing of a single terminal, or
inline testing of a circuit or terminal harness
• Portable storage case fits in 4ʺ tall and 18ʺ deep tool
storage drawers with no wasted space
• Foam organizer includes cut-out silhouette of each
component, part number, description and color for
excellent organization of tools
EEDMCT-KIT EECTDM-FOAM Foam
EECTDM-CASE Case

MTTL900-KIT Multimeter “Y” Terminal Adaptor Kit
• 12 and 24 V DC automotive terminal kit for use with EEDM
Series Digital Multimeters or EECT Circuit Testers
• Unique “Y" adaptor enables testing of single terminal, or
& • Non-intrusive circuit testing with a banana jack adaptor for
inline testing of a circuit or terminal harness
DMM test lead or circuit tester connection
• High-quality silicon wire is flexible in cold conditions and
protected against high heat conditions
TESTING MTTL900-KIT • Carry case fits in 4ʺ tool storage drawers with no
• (34) color coded adaptors makes them easy to find and
select for quick connections
• Includes MTTL7002 threaded to modular adaptor
(Red and Black)
wasted space
MTTL900R-XL Round XL Red Y Terminal
MTTL900R-L Round L Green Y Terminal
MTTL900R-M Round M Brown Y Terminal
MTTL900R-S Round S Blue Y Terminal
MTTL900R-M1 Round M1 Black Y Terminal
MTTL900R-M2 Round M2 Red Y Terminal
MTTL900R-XL
MTTL900S-L Spade L Green Y Terminal
MTTL900S-M Spade M Brown Y Terminal
MTTL900R-L MTTL900S-XL MTTL900S-XL Spade XL Red Y Terminal
MTTL900S-L
MTTL900S-S Spade S Blue Y Terminal
MTTL900S-M1 Spade M1 Black Y Terminal
MTTL900S-M2 Spade M2 Red Y Terminal
MTTL900R-M MTTL900S-M
MTTL900-FOAM Foam Insert
XL and L quantity 2, all others quantity 3.
MTTL900R-S MTTL900S-S

MTTL900R-M1 MTTL900S-M1

MTTL900R-M2 MTTL900S-M2
