JUMP LEADS

Hi-Viz Coiled Jump Leads
• High-grade test leads offer the highest heat and oil resistance,
and exceptional coil memory
• Feature a removable “bed of nails” concept
• After removal, the probe end with a 8-32 brass thread allows for
use of other product accessories
TL624AG Test Leads TL648AR Test Leads TESTING
• Hi-Viz green color; 24ʹ extended length • Hi-Viz red color, 48ʹ extended length TL624AG TL648AR

Intrusive Circuit Testing Modular Adaptors for
Threaded or Modular Leads
TLB6B Adaptor TLBBL6B Adaptor TLBR6B Adaptor
• Straight-nose test clip • 15° bent-nose test clip • 15° bent-nose test clip TLBR6B
with black boot with blue boot with red boot
TLBB6B Adaptor TLBL6B Adaptor TLR6B Adaptor
• 15° bent-nose test clip • Straight-nose test clip • Straight-nose test clip &
with black boot with blue boot with red boot TLR6B

MTTL300 4 pc Straight Jump Lead Set
• Four color-coded test leads help reduce the chance of
wrong connections
• Use as test lead, jumper wires or for shorting out components
when performing ignition system tests
• Each lead is 4ʹ long
MTTL300-1 4ʹ Black Lead, Straight
MTTL300-2 4ʹ Red Lead, Straight
MTTL300-3 4ʹ Green Lead, Straight
MTTL300-4 4ʹ Yellow Lead, Straight MTTL300

MTTL301 4 pc Lead Set (Black/Straight)
• Four sizes facilitate various • Contains 12ʺ MTTL301-1, 18ʺ MTTL301-
applications that make the job easier 2, 24ʺ MTTL301-3, and 10ʹ MTTL301-4 ELECTRONICS
to complete jumper leads
• Alligator clips on both ends securely MTTL301-1 12ʺ Black Lead – Straight MTTL301
grip terminal connections MTTL301-2 18ʺ Black Lead – Straight
• Use as extension leads or for shorting
out components when performing MTTL301-3 24ʺ Black Lead – Straight
ignition system tests MTTL301-4 10ʹ Black Lead – Straight

MTTL310 Series Coiled Jump Leads
Coiled Length, inches Stretched Length, Crocodile Clip
Stock No. Color
(cm) inches (cm) Opening, inches (cm)
MTTL310-1 20 (51) 48 (122) 1/2 (1.27) Black
MTTL310-2 20 (51) 48 (122) 1/2 (1.27) Red
MTTL310-3 20 (51) 48 (122) 1/2 (1.27) Green
MTTL310-4 20 (51) 48 (122) 1/2 (1.27) Yellow
MTTL310 Coiled Jump Leads (Four Colors)
• Four distinct colors facilitate easy identification of test circuits
• Crocodile clips on both ends securely grip terminal connections MTTL310
• Coiled cord stretches to 48ʺ (122 cm) for extra reach
• Soldered and clamped connections provide low signal loss and prolong life

MTTL311 Series Coiled Jump Leads
Stock No. Coiled Length, inches (cm) Stretched Length, inches (cm)
MTTL311-1 10 (25) 12 (30.5)
MTTL311-2 11 (28) 18 (46)
MTTL311-3 13 (33) 24 (61)
MTTL311-4 24 (61) 120 (305)
MTTL311 4 pc Lead Set (Black/Coiled)
• Four sizes facilitate various applications that make the job easier to complete
• Alligator clips on both ends securely grip terminal connections MTTL311
• Soldered and clamped wire connections to alligator clips provide low signal loss
• Do not use in environment with explosive vapor 611
• ‡ These products can expose you to chemicals which are known to the state of California
to cause cancer and reproductive harm. See pages 906-907 for details.
• Read safety precautions on pages W1 to W4
