DIGITAL MULTIMETER ACCESSORIES
ELECTRONICS
EEDMRPMG Gasoline Engine RPM Adaptor
• Ideal for small single-cylinder, 2- and 4-stroke gas engine applications
• Use with any digital multimeter that has DC mV ranges to measure gasoline
engine RPM
• Plug adaptor into the DMM (set to DC mV function), clip lead above engine
spark plug boot and multiply the reading by 10
• Range is 300–6,000 RPM
• Output is 1 mV DC per 10 RPM
• Powered by a 9 V battery (included)

EEDMRPMD Diesel Engine RPM Adaptor
EEDMRPMG • Ideal for small diesel engine applications
• Measures diesel engine RPM
• Plug adaptor into the DMM (set to IP), attach transducer to fuel line leading
to an injector and read RPM on the meter
• Range is 300-4,000 RPM
• Resolution is 1 RPM, powered by a 9 V battery (included)
EEDMRPMD

EEDM5997 DMM RPM Adaptor
• Use with 2- or 4-stroke engines
• Use in conjunction with an automotive feature meter with IP (inductive
pick-up) setting
• For motorcycles, outboard motors, snowmobiles and ATVs with limited or
no ignition shielding
• Internal circuitry filters out noise
& • Non-intrusive pick-up features dual tapped coils to help eliminate errors

EEDM5997 EEDMDVA Direct Voltage Adaptor
TESTING EEDMDVA EEDM5030 EEDM5030 Pressure Adaptor
• Converts outboard marine, motorcycle and other small engine
ignition pulse signals into DC voltage signals
• Adaptor helps identify secondary ignition problems like failed
individual coil packs or poor spark

• Measures pressure from 1–500 PSI and vacuum from 1–29 inHg
• Output is 1mV DC per PSI or inHg
• Ideal for measuring transmission or hydraulic pressure
• 1/4ʺ NPT fitting on the pressure transducer
• Sensor compatible for air or liquid
• 6-1/2ʹ cable length
• Powered by a 9 V battery

EEDMGRNDHD Heavy-Duty Ground Lead for DMM
• Solid-copper clip is a superior quality component for maximum electrical
signal transfer
• Terminal connection ensures a positive electrical signal
• Superior flex black 18-gauge straight silicone wire glides past components
and remains flexible in cold conditions
EEDMGRNDHD
• 90° terminal with a standard 4 mm banana jack
• Length is 6’ (1.83 m)

Temperature Probes and Adaptors
EEDM506D Temperature Adaptor
• Adds temperature capabilities • Use with any multimeter with
to multimeters that do not have 200 m V DC and/or 2 V DC ranges
built-in temperature functions • Provides readings from
• Provides dual temperature -50–1,800 °F
and differential temperature • Includes (2) beaded K-type
measurements for multimeters temp probes
EEDM506D
• Output equals 1 mV per degree • Low battery indicator light
• Accuracy: ±0.75% of full
606 scale + one digit
The Multimeters on this page include a basic lead set.
