DIGITAL MULTIMETERS

®
7-year limited warranty on Snap-on meters.

EEDM596FK EEDM525F EEDM504D EEDM503D TESTING
Automotive Digital Multimeters
Specifications EEDM596FK EEDM525F EEDM504D EEDM503D
Certificate of Calibration Model EEDM596FKCRT EEDM525FCRT EEDM504DCRT —
Display Count 40,000 4,000 Color 4,000 2,000
AC Volts 750 750 750 750 &
DC Volts 1,000 1,000 1,000 1,000
Basic DC Accuracy 0.1% 0.50% 0.50% 0.50%
AC Amps 10 10 10 10
Micro Amps Yes Yes Yes Yes
DC Amps 10 10 10 10
True RMS (Root Mean Square) Yes Yes No No
Resistance, ohms 40M Ohm 40M Ohm 40M Ohm 20M Ohm
Capacitance Yes Yes Yes No
Frequency Yes Yes Yes No
Insulation Test No No No No
Analog Bar Graph Yes Yes Yes No
Auto Range Yes Yes Yes No
Data Hold Yes Yes Yes Yes
Min/Max Yes Yes Yes No
Backlight Always On Always On No No ELECTRONICS
Color Screen Yes Yes No No
Auto Shutoff Yes Yes Yes No
RPM Yes EEDMRPMG (opt.) EEDMRPMG (opt.) EEDMRPMG (opt.)
Adjustable Trigger Level Yes No No No
Noise Reduction Circuit Yes No No No
Temperature EEDMTEMP-1 EEDMTEMP-1 (opt.) EEDM506C (opt.) EEDM506C (opt.)
Duty/Dwell Yes Duty Only Duty Only No
mS Pulse Width Yes No No No
Comp. Output (USB) Yes No No No
®
UL Listed cULus 61010-1 cULus 61010-1 cULus 61010-1 cULus 61010-1
CATIII 750 V AC, CATIII 750 V AC, CATII 750 V AC, CATII 750 V AC,
CAT Rating CATIII 1,000 V DC, CATIII 1,000 V DC, CATII 1,000 V DC, CATII 1,000 V DC,
CATIV 600 V AC/DC CATIV 600 V AC/DC CATIII 600 V AC/DC CATIII 600 V AC/DC
Easy Open Battery and Fuse Door EEDM5F-DOOR EEDM5F-DOOR Yes Yes
Glitch Capture — No No No
Blown Fuse Identifier Yes Yes Yes Yes
Dimensions, inches 4.7 x 7.7 x 1.6 4.7 x 7.7 x 1.6 7-3/4 x 3-3/4 x 1-1/2 7-3/4 x 3-3/4 x 1-1/2
EEDM5F-POUCH,
Case or Zipper Pouch EEDM5F-CC EEDM504B4 EEDM504B4 (opt.)
EEDM5F-CC (opt.)
Test Leads EEDMLEADSET EEDMLEADSET EEDM504B3 EEDM504B3
EEDMFUSE-7, EEDMFUSE-7, EEDMFUSE-1, EEDMFUSE-1,
Fuses
EEDMFUSE-8 EEDMFUSE-8 EEDMFUSE-2 EEDMFUSE-4
Low Pass Filter (LPF) Yes Yes No No
TECHNICAL SUPPORT: 1-888-382-6522
Multimeters on this page include a basic lead set.

603
• Do not use in environment with explosive vapor
• Read safety precautions on pages W1 to W4
