DIGITAL MULTIMETER ACCESSORIES

Temperature Probes and Adaptors
• Proven K-type thermocouple for connection to the DMM
• Can be used with the optional EEDM506D temperature
adaptor for multimeters that do not have a built-in
temperature function
EEDMTEMP-1 Temperature Adaptor and Probe EEDMTEMP-2 TESTING
EEDMTEMP-2 Beaded Temp Probe EEDMTEMP-1
EEDMTEMP-3 Temp Adaptor

EETH501D 8ʺ Liquid Temperature Probe
EETH502D 8ʺ Surface Temperature Probe EEDMTEMP-3
EETH503D 8ʺ Tip Air Temperature Probe
• Patented Instinct handle provides comfort and
®
grip while probing and positioning the tip &
• Stainless steel shank will not corrode EETH501D
• 4ʹ flexible coil thermo cable keeps the multimeter
a safe distance from heat or cold
• Proven K-type thermocouple for connection to the DMM EETH502D
• Can be used with the optional EEDM506D temperature adaptor
for multimeters that do not have a built-in temperature function
• For Multimeters that do have the temperature function built EETH503D
in, the EETH series probes require the optional adaptor
EEDMTEMP-3
TEST LEADS

EEDM504B3 Test Lead Set with Alligator Clips
• Standard vinyl-jacket test lead set with screw-on alligator clips provides basic
application testing needs
• Screw-on probe protectors limit the metal probe shaft from touching during testing
for safety (protectors should be removed when using alligator clips or adaptors) ELECTRONICS

TL2A Test Lead Set EEDM504B3
• High-grade test lead pair fits all meters using standard banana plug jacks
• Nonslip prodding probes have stainless steel points
• Coiled cords stretch to more than 60ʺ
• Screw-on alligator clips convert the leads to jumper wires
• Banana plug screws allow use with most multimeters
TL2A
MTTL725 Hard Tip DMM Test Lead Set
• 58ʺ length offers the advantage of a • 90° serrated flexible strain relief for
greater reach improved long life
• Silicone double insulation wire jacket for • Special tip configuration is designed
safety—if outer jacket is nicked, a white to accept push-on accessories
underlayer is revealed • CAT III 1,000 V and CAT IV 1,000 V
safety rating
MTTL725
MTTL575 DMM Test Lead Set
• 70ʺ length offers greater flexibility • Protective plastic collar surrounds
in reach the banana jack for safety
• Silicone double insulation wire jacket for • Enables long-distance testing such as
safety—if outer jacket is nicked, a white brake lights and underhood while in
underlayer is revealed the cockpit
• 90° serrated flexible strain relief • Acts as an extension cord for an even
protects the wire from being kinked at longer reach when servicing
the probe or terminal ends for longer life large equipment
• Push/pull finger collar for sure grip • Can be used in high-heat situations
pressure putting on or pulling off around manifolds or exhaust systems
• CAT III 1,000 V and CAT IV 600 V • Jacket material will not burn, MTTL575
safety rating even in a flame
• Remains flexible in extreme cold where
poly products get hard or stiff
607
• Do not use in environment with explosive vapor
• Read safety precautions on pages W1 to W4
