AIR: 1/2" DRIVE IMPACT WRENCHES (Blue-Point )
®
TOOLS

POWER AT5500

AT570
AT5500T
1/2ʺ Drive Impact Wrench (Blue-Point )
®
EU/CE – DE, ES, FR, IT, NL, UK (all models)
Specifications AT5500 † AT570 † AT5500T
Drive Size, inches (mm) 1/2 (13) 1/2 (13) 1/2 (13)
Maximum Torque, ft-lb (N•m) 550 (745) 570 (773) 550 (745)
Free Speed, RPM 7,400 6,900 (F), 7,000 (R) 9,000
Blows Per Minute, BPM 1,200 1,050 1,200
Anvil Type Friction Ring Friction Ring Friction Ring
Air Consumption, Free Speed, CFM (SCFM) [l/min] 4.2 (30) [118.9] 5.0 (36) [142] (F), 5.3 (38) [150] (R) 4.2 (30) [119]
Air Inlet Thread Size 1/4ʺ-18 NPT 1/4ʺ-18 NPT 1/4ʺ-18 NPT
Recommended Hose Size, inches (mm) 3/8 (10) 3/8 (10) 3/8 (10)
Vibration Level, m/s 2 4.0 95 4.0
Sound Level dB(A) Pressure 94 6.08 94
Length, inches (mm) 7.9 (20) 7.24 (184) 5.9 (150)
Weight, lb (kg) 6.4 (2.9) 4.08 (1.87) 5.0 (2.29)
Vinyl Boot AT5500BOOT AT570BOOT AT5500TBOOT

AT5500 1/2ʺ Drive Impact Wrench AT570 1/2ʺ Drive Impact Wrench AT5500T 1/2ʺ Drive Tight-Access
®
®
(Blue-Point ) (Blue-Point ) Impact Wrench (Blue-Point )
®
• 550 ft-lb of torque, 7,400 RPM, • Used on automotive and • 550 ft-lb of torque, 9,000 RPM,
1,200 BPM truck fasteners 1,200 BPM
• Built-in five-position adjustable • Shot-peen anvils for • Compact and lightweight for reduced
air regulator plus a variable-speed improved durability user fatigue
trigger for maximum user control • Reverse-bias motor provides • Twin-hammer impact mechanism
• Twin-hammer impact mechanism additional torque hits harder and delivers increased
is designed to hit hard yet offer • Three-position regulator tool longevity
tool longevity to control power • Polished aluminum housing is
• Ball-bearing-mounted motor creates • One-handed forward/reverse lever durable and easy to clean
a smooth running operation for for user convenience • Ball-bearing-mounted motor for
longer tool life • Composite housing with an smooth running operation
• 1 pc aluminum housing provides a aluminum nose combine to • Removable brass inlet filter protects
durable tool deliver a durable, lightweight the tool from grit and debris
• Tapered nose increases accessibility and balanced unit • Large forward/reverse lever for
to confined areas • Twin-hammer impact mechanism one-handed operation
• Inlet filter screens out dirt and grit; delivers hard-hitting blows to
easy-to-remove filter for cleaning quickly remove stubborn fasteners
• One year limited warranty
