AIR: 3/8", 1/4" DRIVE RATCHETS
TOOLS PTR72

POWER PTR2500

Air Ratchets (Snap-on ) PTR2505
®
Specifications PTR72 * PTR2500 PTR2505
Drive Size, inches (mm) 3/8 (10) 1/4 (6) 3/8 (10))
Maximum Torque, ft-lb (N•m) 70 (95) 0–35 (0–47) 0–35 (0–47)
Free Speed, RPM 275 225 225
Air Consumption, Free Speed, CFM (SCFM) [l/min] 4.5 (32) [127] 1.7 (11) [48] 1.7 (11) [48]
Air Inlet Thread Size 1/4ʺ-18 NPT 1/4ʺ-18 NPT 1/4ʺ-18 NPT
Recommended Hose Size, inches (mm) 3/8 (10) 3/8 (10) 3/8 (10)
Vibration Level, m/s 2 5.2 2.5 2.5
Sound Level dB(A) Pressure 92.9 84 84
Length, inches (mm) 12.1 (308) 7.8 (197) 7.8 (197)
Weight, lb (kg) 2.9 (1.3) 1.4 (.6) 1.4 (.6)
Vinyl Boot YA889 (included) YA905 (included) YA905 (included)
Warranty 2 Year 1 Year —
PTR72 3/8ʺ Drive Super-Duty Air Ratchet PTR2500 1/4ʺ Drive Mini Air Ratchet
• 70 ft-lb of torque output to remove stubborn fasteners • Balanced, lightweight housing for superior comfort and
• Easily withstands 158 ft-lb of manual torque control with less user fatigue
• 275 RPM free speed for fast removal and installation • Soft grip handle provides increased comfort while
of fasteners reducing vibration and insulating from the cold
• “Stop lock” pins prevent ratchet pawl lockup • Hard-coated motor plates help reduce scoring for longer
• Steel wear bushings reduce ratchet head wear tool life
• Dual-pawls for added strength • Large forward/reverse knob makes it easy to switch
• Tip valve-style trigger is easy to feather for directions, even with greasy hands
greater control • Zerk fitting allows the ratchet head to be lubricated for
• Large selector knob for easy direction change longer tool life
• Adjustable composite exhaust directs the airflow away • Variable-speed trigger allows for slow motor start-ups
from work PTR2505 3/8ʺ Drive Mini Air Ratchet
• Cushion grip for added comfort and control
Colors Available

Red Green Hi-Viz
* G HV
ADD SUFFIX TO STOCK NUMBER FOR SPECIAL COLORS
