AIR: HAMMERS Air Hammer
TOOLS PH3050BR Specifications PH3050BR* 0.401 (10.1)

AT2050 †
3/4 (19)
Bore Diameter, inches (mm)
3/4 (19)
Blows Per Minute, BPM
2,500
3,400
3 (76)
2.75 (70)
Piston Stroke, inches (mm)
0.401 (10.1)
Shank Opening, inches (mm)
2.1 (14) [59]
2.5 (18) [71]
Air Consumption, Free Speed, CFM (SCFM) [l/min]
1/4ʺ-18 NPT
1/4ʺ-18 NPT
Air Inlet Thread Size
5/16 (8)
5/16 (8)
Recommended Hose Size, inches (mm)
8.6
2.8
Vibration Level, m/s
91.4
99
Sound Level dB(A) Pressure
9.0 (228)
7.4 (187)
Length, inches (mm) 2 PH3050RBOOT AT2050BOOT
POWER ADD SUFFIX TO STOCK NUMBER PH3050BR Super-Duty Air Hammer
Weight, lb (kg)
5.9 (2.7)
4.6 (2.1)
Colors Available
Vinyl Boot
†
Hi-Viz
Green
Red
G
HV
*
• Dual elastomer cushions absorb shock and vibration to reduce user fatigue
• Phenolic (Kevlar -reinforced) flutter disc provides long life
®
FOR SPECIAL COLORS
• Direct multiport front exhaust keeps air and debris away from the user
• High-grade steel barrel for greater strength
• Variable-speed soft-touch trigger provides featherability for greater control
• Four-position built-in air regulator varies power for different applications
• Air line screen helps prevent foreign particles from clogging the
trigger mechanism
• Hardened-steel piston delivers harder blows for maximum impact
• Includes PH200D Quick-Change Chuck Retainer
PH3050BRCH4 Super-Duty Air Hammer Set
• Set includes Air hammer (PH3050BR), Quick Change Retainer (PH200D),Flat
Chisel (PHG55A),Panel Cutter (PHG57B), Tapered Punch (PHG59A), and
AT2050
Muffler Cutter (PHG87) in a storage case
®
AT2050 Heavy-Duty Air Hammer (Blue-Point )
• Intended for heavy-duty applications, such as cutting large bolts and rivets,
separating ball joints, cutting heavy-gauge sheet metal and driving bushings
• 3,400 BPM
• Quick-change chuck makes bit changing easy
• Variable-speed trigger with a built-in speed regulator
• Comfort grip handle for less user fatigue
• Hard-hitting; gets the job done quicker
Retainer Chuck
PH200D Universal Quick-Change Chuck Retainer
• Use for fast and easy insertion/removal of air hammer bits
• Non-turning insert design reduces wear for longer tool life
• Constructed from high-grade steel—insert is constructed from durable
polyurethane elastomer
PH200D
• Universal design fits most air hammers
• Knurled collar provides a solid gripping surface, even with greasy hands
AIR: DIE GRINDERS
PTGR100 PTGR110 PTGR200 PTGR205 PTGR210
Mini and Standard Die Grinders, 1/4" Collet
Mini Series Standard Series
Specifications PTGR100 ‡ PTGR110 ‡ PTGR200 PTGR205 PTGR210
Collet Size, inches 1/4 1/4 1/4 1/4 1/4
Rated Power, HP (kW) 0.3 (.2) 0.3 (.2) .5 (.3) .5 (.3) .5 (.3)
Free Speed, RPM 25,000 25,000 23,000 23,000 23,000
Air Consumption, Free Speed, CFM (SCFM) [l/min] 1.7 (11) [48] 1.7 (11) [48] 3.2 (23) 3.2 (23) 3.2 (23)
Air Inlet Thread Size 1/4ʺ-18 NPT 1/4ʺ-18 NPT 1/4ʺ-18 NPT 1/4ʺ-18 NPT 1/4ʺ-18 NPT
Recommended Hose Size, inches (mm) 3/8 (10) 3/8 (10) 3/8 (10) 3/8 (10) 3/8 (10)
Vibration Level, m/s 2 3.2 6.3 2 3 5.2
Sound Level dB(A) Pressure 83.3 85.9 85.1 85.9 86
Length, inches (mm) 6.1 (155) 5.75 (146) 6.9 (175) 10.9 (276) 64 (162)
Weight, lb (kg) 1 (0.4) 1.2 (0.5) 1.2 (.5) 2.1 (.95) 1.4 (.63)
