AIR: 3/8" DRIVE IMPACT WRENCHES (Blue-Point )
®

AT351 POWER

AT235MCA
AT370 AT380A AT2538

AT1038
3/8ʺ Drive Heavy-Duty (Blue-Point ) TOOLS
®
Specifications AT370 AT380A † AT2538 † AT1038 † AT351 AT235MCA
Drive Size, inches (mm) 3/8 (10) 3/8 (10) 3/8 (10) 3/8 (10) 3/8 (10) 1/4 (6)
Max Torque, ft-lb (N•m) 320 (434) 175 (230) 275 (373) 190 (257) 175 (237) 25 (34)
Free Speed, RPM 9,000 (F), 9,500 (R) 8,700 9,000 4,150 9,700 13,000
Blows Per Minute, BPM 1,050 1,680 1,500 1,950 1,200 2,900
Air Consumption, Free Speed, 4.4 (326) [125] (F), 3.9 (28) [111] 4.3 (—) 3.7 (—) [104.77] 2.5 (18) [71] 1.67 (12) [47]
CFM (SCFM) [l/min] 4.7 (34) [133] (R)
Air Inlet Thread Size 1/4ʺ-18 NPT 1/4ʺ-18 NPT 1/4ʺ-18 NPT 1/4ʺ-18 NPT 1/4ʺ-18 NPT 1/4ʺ-18 NPT
Recommended Hose Size, 3/8 (10) 3/8 (10) 90 (6.2) 90 (6.2) 3/8 (10) ID min. 3/8 (10) ID min.
inches (mm)
Vibration Level, m/s 2 3.25 3.5 8.6 8.2 96.6 <2.5
Sound Level dB(A) Pressure 92 94 100 94.4 3.09 95.1
Length, inches (mm) 6.3 (160) 6.5 (165) 4.29 (109) 13.15 (334) 7.6 (194) 6.2 (158)
Weight, lb (kg) 2.62 (1.19) 3.0 (1.36) 2.96 (1.34) 3.47 (1.574) 2.5 (1.2) 1.4 (.64)
Vinyl Boot AT370BOOT AT380ABOOT — — — —
†
AT370 3/8ʺ Drive Impact Wrench AT1038 3/8ʺ Drive Right-Angle Impact Wrench
• Used on automotive and truck fasteners (Blue-Point )
®
• Shot-peen anvils for improved durability • Low-profile right-angle head for access to tight spaces
• Reverse-bias motor provides additional • Hard-hitting jumbo hammer mechanism
breakaway torque • Multiple speed settings—two forward and one reverse
• Three-position regulator to control power • Forward/reverse lockout mechanism
• One-handed forward/reverse lever for convenient use • Variable-speed trigger
• Composite housing with an aluminum nose combine to • Gear oil lubrication for reduced component wear and
deliver a durable, lightweight and balanced unit longer tool life
• Twin-hammer impact mechanism delivers hard-hitting • One year limited warranty
blows to quickly remove stubborn fasteners AT351 3/8ʺ Drive Impact Wrench (Blue-Point )
®
®
AT380A 3/8ʺ Drive Impact Wrench (Blue-Point ) • Built-in air inlet swivel
• Built-in, five-position adjustable air regulator plus a • Eight-position power regulator
variable-speed trigger for maximum user control • Rotary action air motor is ball bearing mounted for
• Aluminum housing provides a lightweight yet balance, speed and power
durable tool • Ideal tool for small engine repair and bench work
• Tapered nose increases accessibility to confined areas AT235MCA 1/4ʺ Drive Micro Impact Wrench
• Ball-bearing-mounted motor creates a smooth-running (Blue-Point )
®
operation for less user fatigue
• Brass inlet filter screens out dirt and grit; easy-to-remove • 25 ft-lb of torque
filter for cleaning • Balanced, lightweight, reduces fatigue
• Twin-hammer impact mechanism is designed to hit hard • Durable composite housing
yet offer tool longevity • Oversized trigger with variable-speed
• One year limited warranty • Convenient one-handed forward/reverse lever
• Exhaust is released through the bottom of the handle,
AT2538 3/8ʺ Drive Compact Impact Wrench (Blue-Point ) away from the work area
®
• 275 ft-lb of torque ®
• Jumbo hammer mechanism AT380BOOT Air Impact Wrench Boot (Blue-Point )
• Thumb-operated forward/reverse lever • Protective vinyl boot for air impact wrench

®
• Three forward speeds and one reverse AT370BOOT Vinyl Boot (AT370 Series) (Blue-Point )
• Exhaust is released through the bottom of the handle,
away from the work area
• One year warranty
555
• Use only impact sockets and accessories with impact wrenches
• Read safety precautions on pages W1 to W4
