AIR: CUT-OFF TOOLS
TOOLS Cut-Off Tool 3.2 (23) [90]

PTC250
Specifications
3 (76)
Wheel Size, inches (mm)
0.5 (.37)
Rated Power, HP (kW)
Free Speed, RPM
22,000
Air Consumption, Free Speed, CFM (SCFM) [l/min]
Air Inlet Thread Size
6
Vibration Level, m/s
86.1
Sound Level dB(A) Pressure
7.2 (183)
Length, inches (mm) 2 1/4ʺ-18 NPT
1.6 (.73)
POWER PTC250 3ʺ Cut-Off Tool
Weight, lb (kg)
PTC250
AT150-20A
3” Cutter Wheels (36-Grit) (opt.)
AT150C29A
3” Cutter Wheels (54-Grit) (opt.)
• Adjustable cutting wheel guard rotates to any safe and convenient position
• Adjustable rear exhaust directs airflow away from the work area
• Thermally balanced air motor acts as an internal cooling system to protect
moving parts; efficiently routes air to control the surface temperature
of the tool
• Adjustable regulator matches tool speed to job requirements
• Variable-speed paddle-style safety trigger prevents accidental start-ups
• Collet system on the die grinders provides bit retention and minimal runout
• High-quality single-row bearings allow for smooth operation and minimal
runout to keep the tool running longer
• Black Alcryn grips with red Snap-on logo for improved comfort and
®
®
resistance to automotive fluids
• Easy wheel changing using standard wrenches
• Optional accessories include Cut-Off Wheels (AT150-20A)
Reversible Cut-Off Tools (Blue-Point )
®
Specifications AT154RA AT157R
Wheel Size, inches (mm) 4 (102) 3 (76)
Rated Power, HP (kW) 0.7 (0.5) 0.45 (.33)
Free Speed, RPM 13,000 20,000
Air Consumption, Free Speed,
CFM (SCFM) [l/min] 3.1 (22) [87] 3.5 (25) [99]
Air Inlet Thread Size 1/4ʺ-18 NPT 1/4ʺ-18 NPT
AT154RA Recommended Hose Size, inches (mm) 3/8 (10) 3/8 (10)
Vibration Level, m/s 2 3.07 <3.8
Sound Level dB(A) Pressure 85 100
Length, inches (mm) 14.3 (365) 7.3 (185)
Weight, lb (kg) 3.3 (1.5) 1.9 (.86)
3ʺ Cutter Wheels (36-Grit) (opt.) — AT150-20A
3ʺ Cutter Wheels (54-Grit) (opt.) — AT150C29A
4ʺ Cutter Wheels AT154RWHLMP —

AT154RA 4ʺ Reversible AT157R 3ʺ Reversible Cut-Off Tool
Cut-Off Tool (Blue-Point ) (Blue-Point )
®
®
• 14.3ʺ overall length • Ideal for use in body shops and other general
provides extended reach automotive applications
for easier access • Spark direction control
• Reverse mode controls • Extended reach for hard-to-access areas
direction of sparks for safety • Built-in speed regulator for fine tuning
• Exhaust is diffused through • Safety throttle lever
AT157R the rear of the tool away • Comfort grip handle
from work surface • Uses wheels only rated above 18,000 RPM
• Side handle provides • Recommended for cutting mufflers,
additional tool control hose clamps, bolts and sheet metal
• 1 year limited warranty
