AIR: FINISHING TOOLS (Blue-Point )
®

AT425R POWER
AT408 AT411A
®
Dual-Action and Geared Sanders (Blue-Point ) Reversible Disc Sander (Blue-Point )
®
Specifications AT408 AT411A Specifications AT425R
Style Geared (NV) Dual Action Style Reversible Hi-Speed
Pad/Disc Size, Dia., 8 (203) 6 (152) Pad/Disc Size, Dia., inches (mm) 5 (127)
inches (mm) Rated Power, HP (kW) 0.45 (.33)
Rated Power, HP (kW) 0.5 (.37) 0.5 (.37) Free Speed, RPM 13,000
Free Speed, RPM 850 10,000
Spindle Thread, inches 7/16ʺ-20 UNC
Spindle Thread, inches 5/16ʺ-24 5/16ʺ-18 UNC
Air Consumption, Free Speed, CFM (SCFM)
Air Consumption, Free Speed, CFM 5 (36) [142] 5 (36) [142] [l/min] 4.3 (31) [122]
(SCFM) [l/min]
Air Inlet Thread Size 1/4ʺ-18 NPT TOOLS
Air Inlet Thread Size 1/4ʺ-18 NPT 1/4ʺ-18 NPT
Recommended Hose Size, inches (mm) 3/8 (10)
Recommended Hose Size, inches (mm) 3/8 (10) 3/8 (10) ID min.
Vibration Level, m/s 2 <0.8
Vibration Level, m/s 2 3.7 3.7
Sound Level dB(A) Pressure 93
Sound Level dB(A) Pressure 87 79
Length, inches (mm) 5.3 (135)
Length, inches (mm) 11 (281) 8 (203)
Weight, lb (kg) 2.8 (1.28)
Weight, lb (kg) 4.8 (2.18) 4.7 (2.14)
Replacement Pad/Disc AT425R-24
Replacement Pad/Disc AT408-2 AT411A-1 3ʺ Replacement Pad (opt.) AT425R-22

4ʺ Replacement Pad (opt.) AT425R-23
®
AT408 8ʺ Geared Sander (Blue-Point )
• Rear diffused exhaust AT425R 5ʺ Reversible High-Speed Sander
• Built-in adjustable-speed regulator ®
• Removable brass filter screens out debris (Blue-Point )
®
AT411A 6ʺ Dual-Action Sander (Blue-Point ) • Used in body shops and other general automotive
• Used for fine sanding operations and swirl-free finishing applications
• Comfort handle helps reduce fatigue • Comfort grip handle
• Converts from rotary to random orbit action by • Built-in speed regulator
sliding drive plate • One-handed forward/reverse lever
• Built-in thumb-wheel speed regulator • Includes (3) backing discs: 3, 4 and 5ʺ
AT406C
AT475A
®
®
Orbital Sanders(Blue-Point ) In Line Sanders (Blue-Point )
Specifications AT406C Specifications AT475A
Pad/Disc Size, Dia., inches (mm) 6 (152) Pad/Disc Size, Dia., inches (mm) 2-3/4 x 17-1/2
Rated Power, HP (kW) .25 (.19) Free Speed, RPM 1,800
Free Speed, RPM 12,000 Air Consumption, Free Speed, CFM (SCFM) [l/min] 2.3 (17) [65]
Spindle Thread, inches 5/16ʺ-24 Air Inlet Thread Size 1/4ʺ-18 NPT
Air Consumption, Free Speed, CFM (SCFM) [l/min] 2.5 (18) [71] Recommended Hose Size, inches (mm) 3/8 (10) ID min.
Vibration Level, m/s 2 2.8 Vibration Level, m/s 2 14.9
Sound Level dB(A) Pressure 85 Sound Level dB(A) Pressure 87
Length, inches (mm) 8.6 (21.9) Length, inches (mm) 16 (406)
Weight, lb (kg) 1.5 (0.7) Weight, lb (kg) 6.8 (3.09)
Replacement Pad/Disc AT475A-29
AT406C 6ʺ Orbital Palm Sander (Blue-Point )
®
• Lightweight and durable composite housing
®
• Built-on power regulator for optimized power control AT475A 16ʺ Heavy-Duty Inline Sander (Blue-Point )
• Well-balanced for smooth handling • 5/8ʺ stroke
• For use with accessories rated above 12,000 RPM • Minimal vibration
• Used for fast material removal
Replacement Sander Pads • Pad has positive locking clamps
PSO4625-2H 6ʺ Sander Replacement Pad
• Non-vacuum replacement pad for PS4612/PSF4612 sander with VELCRO Brand fasteners
®
569
• Do not use grinding discs on sanders
• Read safety precautions on pages W1 to W4
