AIR: CUT-OFF TOOLS (BluePoint )
®

®
Cut-Off Tool (Blue-Point )
Specifications AT153
Wheel Size, inches (mm) 3 (76)
Rated Power, HP (kW) 0.5 (0.37) POWER
Free Speed, RPM 17,000
Air Consumption, Free Speed, CFM (SCFM) [l/min] 3.5 (24) [99.1]
Air Inlet Thread Size 1/4ʺ-18 NPT
Recommended Air Pressure, PSIG (kPa) 90 (620)
Recommended Hose Size, inches (mm) 3/8 (10)
Vibration Level, m/s 2 <2.86
Sound Level dB(A) Pressure 85 AT153
Length, inches (mm) 7.3 (185)
Weight, lb (kg) 3.3 (1.5)
3” Cutter Wheels (36-Grit) (opt.) AT150-20A
3” Cutter Wheels (54-Grit) (opt.) AT150C28A

AT153 Cut-Off Tool (3ʺ) (Blue-Point ) TOOLS
®
• Compact size is excellent for accessing areas with limited working space
• Heavy-duty bevel gears for tool longevity
• Indexing adjustable guard controls the direction of sparks
• Spindle lock eliminates the need for special wrenches for fast change of
cut-off wheels
• Adjustable built-in regulator easily adjusts up to 17,000 RPM free speed
AT150A Cutter

AIR: GRINDERS (BluePoint )
®

Grinder (Blue-Point )
®
Specifications AT415B
Wheel Size, inches (mm) 4-1/2 (114)
Rated Power, HP (kW) 0.86 (.64)
Free Speed, RPM 12,000
Air Consumption, Free Speed, CFM (SCFM) [l/min] 3.2 (23) [91]
Air Inlet Thread Size 1/4ʺ-18 NPT
Recommended Air Pressure, PSIG (kPa) 90 (620)
Recommended Hose Size, inches (mm) 3/8 (10)
Vibration Level, m/s 2 5.1
Sound Level dB(A) Pressure 87 AT415B
Length, inches (mm) 10 (254)
Weight, lb (kg) 4.2 (1.9)
Grinding Disc Set (optional) AT415A51

AT415B 4-1/2ʺ Compact Grinder (Blue-Point )
®
• Includes (1) grinding disc

565
• Do not use grinders or cut-off tools without the guard
• Do not use grinder accessories above their maximum rated RPM
• Read safety precautions on pages W1 to W4
