AIR: QUICK REFERENCE CHART

®
Grinders (Blue-Point )
Rated
Disc Size, Dia., Free Speed, Air Consumption, Free Speed, Vibration Sound Level Length, Weight,
Stock No. Power, HP
inches (mm) RPM CFM (SCFM) [l/min] Level, m/s 2 dB(A) Pressure inches (mm) lb (kg)
(kW)
AT415B * † 4-1/2 (102) 0.86 (.64) 12,000 3.2 (23) [91] 5.1 87 10 (254) 4.2 (1.9)
Blue-Point ® POWER
®
Heavy-Duty Air Hammers (Blue-Point )
Shank Air Consumption, Sound
Bore Diameter, Blows Per Piston Stroke, Vibration Length, Weight,
Stock No. Opening, Free Speed, CFM Pressure
inches (mm) Minute, BPM inches (mm) Level, m/s 2 inches (mm) lb (kg)
inches (mm) (SCFM) [l/min] Level, dB(A)
PH3050BR 3/4 (19) 2,500 3 (76) 0.401 (10.1) 2.1 (14) [59] 2.8 91.4 9.0 (228) 5.9 (2.7)
AT2050 † 3/4 (19) 3,400 2.75 (70) 0.401 (10.1) 2.5 (18) [71] 8.6 99 7.4 (187) 4.6 (2.1)
†
Die Grinders
Air Consumption,
Collet Size, Rated Power, Free Speed, Vibration Sound Level Length, inches Weight, lb
Stock No. Free Speed, CFM
inches HP (kW) RPM Level, m/s 2 dB(A) Pressure (mm) (kg)
(SCFM) [l/min]
PTGR100 ‡ 1/4 0.3 (.2) 25,000 1.7 (11) [48] 3.2 83.3 6.1 (155) 1 (0.4) TOOLS
PTGR110 ‡ 1/4 0.3 (.2) 25,000 1.7 (11) [48] 6.3 85.9 5.75 (146) 1.2 (0.5)
PTGR200 1/4 .5 (.3) 23,000 3.2 (23) 2 85.1 6.9 (175) 1.2 (.5)
PTGR205 1/4 .5 (.3) 23,000 3.2 (23) 3 85.9 10.9 (276) 2.1 (.95)
PTGR210 1/4 .5 (.3) 23,000 3.2 (23) 5.2 86 64 (162) 1.4 (.63)
AT115 † 1/4 0.45 (.33) 22,000 4 (29) [113] <2.5 95 6.5 (165) 1.3 (.61)
AT105 † 1/4 0.45 (.33) 22,000 4 (29) [113] <2.5 102 6.5 (165) 1.3 (.61)
AT109 † 1/4 0.2 (.15) 20,000 2.1 (15) [59] 2.5 93 5.5 (140) 1.1 (.50)
AT118 † 1/4 0.2 (.15) 20,000 4.0 (29) [113] 2.5 93 5.5 (140) 1.1 (.50)
AT119 † 1/4 0.2 (.15) 20,000 3 (15) [59] <6.92 100 1.1 (50) 6.81 (173)
AT116 † 1/4 0.2 (.15) 20,000 3 (15) [59] 3 100 6.5 (165) 1.1 (50)
AT120L † 1/4 (6.35) 0.22 (.164) 23,000 3 (22) [85] 1.83 77 11.02 (280) 1.45 (.66)
AT120LRA † 1/4 (6.35) 0.45 (.335) 18,000 3.3 (24) [93.4] 1.83 79 11.25 (285) 1.63 (.74)
AT1070A † 1/8 — 75,000 1 (7) [28] 2.0 72 5.3 (135) .55 (0.25)
AT1070RA † 1/8 — 75,000 1 (7) [28] 2.0 72 5.9 (150) .46 (0.21)
*See page 562 for AT109DGK Die Grinder Kit specifications.
†

Orbital and Geared Sanders
Pad/Disc Rated Free Spindle Air Consumption, Vibration Sound Length, Weight,
Stock No. Size, Dia., Style Power, Speed, Thread, inches Free Speed, CFM Level, Level dB(A) inches lb (kg)
inches (mm) HP (kW) RPM (SCFM) [l/min] m/s 2 Pressure (mm)
PSO4525 5 (127) Orbital .25 (.19) 12,000 1/4ʺ-20 2 (14) 2.3 75.3 5 (127) 1.7 (.77)
PSO4625 6 (152) Orbital .25 (.19) 12,000 1/4ʺ-20 2 (14) 2.3 75.3 6 (152) 2.2 (1)
Orbital
PSOF4625 † 6 (152) Finishing .25 (.19) 12,000 1/4ʺ-20 2 (14) 2.1 74.9 6 (152) 2.4 (1.1)
Orbital
PSOF4325 † 3 Finishing .25 (.19) 12,000 1/4ʺ-20 2 (14) 2.1 74.9 3 (76) 1.44 (.65)
AT408 † 8 (203) Geared (NV) 0.5 (.37) 850 5/16ʺ-24 5 (36) [142] 3.7 87 11 (281) 4.8 (2.18)
AT411A † 6 (152) Dual Action 0.5 (.37) 10,000 5/16ʺ-18 UNC 5 (36) [142] 3.7 79 8 (203) 4.7 (2.14)
AT425R † 5 (127) Reversible 0.45 (.33) 13,000 7/16ʺ-20 UNC 4.3 (31) [122] <0.8 93 5.3 (135) 2.8 (1.28)
Hi-Speed
AT406C † 6 (152) Orbital .25 (.19) 12,000 5/16ʺ-24 2.5 (18) [71] 2.8 85 8.6 (21.9) 1.5 (0.7)
AT475A † 2-3/4 x 17-1/2 Inline — 1,800 — 2.3 (17) [65] 14.9 87 16 (406) 6.8 (3.09)
AT401MCA † 3 (76) Micro Surface 0.25 (.19) 15,000 1/4ʺ-20 2.1 (15) [59] <2.5 84 4.7 (119) 0.97 (0.44)
Prep
AT402MCA † 3 (76) Micro Sander 0.25 (.19) 15,000 5/16ʺ-24 UNF 2.1 (15) [59] <2.5 84 5.2 (133) 1.1 (.50)
AT403MCA † 3 (76.2) Micro Polisher 0.25 (.19) 6,000 5/16ʺ-24 UNF 2.2 (16) [62] <2.5 86 5.6 (143) 1.3 (0.60)
Vertical
AT450DP † 7 (177) Polisher 0.7 2,500 5/8–11 3.6 9 — 16 (406) 4.95 (2.25)
Material
PTGR280 ‡ — Removal Tool 0.45 (.33) 3,500 — 4 (28) [113] 2.8 85 12 (304) 2.4 (1.09)
PSG4645 6 (152) Geared (NV) 0.42 (.33) 1,000 3/8 3 (21.7) [85] 5.9 80 11 (281) 3.7 (1.70)
PSG4645V 6 (152) Geared (V) 0.42 (.33) 1,000 3/8 3 (21.7) [85] 5.9 80 11 (281) 3.7 (1.70)
PSG4845 8 (203) Geared (NV) 0.42 (.33) 1,000 3/8 3 (21.7) [85] 5.9 80 11 (281) 4 (1.82)
PSG4845V 8 (203) Geared (V) 0.42 (.33) 1,000 3/8 3 (21.7) [85] 5.9 80 11 (281) 4 (1.82)
PSDF4600 6 (152) Dual-Function — 1200 — 3 (22) [85] 4.7 — 11 (281) 3.7 (170)
PSDF4600V 6 (152) Dual-Function — 1200 — 3 (22) [85] 4.7 — 11 (281) 3.7 (170)
†
• ‡ These products can expose you to chemicals which are known to the state of California to cause 547
cancer and reproductive harm. See pages 906-907 for details.
• Read and follow safety messages for each type of Air Tool on the following pages and the safety
precautions on pages W1 to W4
