TOOLS DIESEL TOOLS SCFM2538 S6201

Crowfoot Wrench
S6201 M20 x 1.5 Rethreader Tap
SCFM2538 3/8ʺ Drive Cummins Wastegate Solenoid
• Manufactured from special steel with a higher
Crowfoot Wrench ® Specialty Service Tools
alloy content
• Manufactured from steel with a higher alloy content • Industrial finish helps protect against corrosion
HAND • Crowfoot design and square drive allow for proper
• Heat treated for optimum strength and durability
• Precision machined and heat treated for optimum
• Crowfoot design helps to not damage the solenoid while
strength and durability
providing access to it during removal or installation
torquing of the solenoid during installation
®
®
DIESEL: FORD /NAVISTAR

GENERAL
YA9340
SRD6
Belt Tensioning Tools
®
SRD6 Belt Tensioner Release Tool YA9340 ‡ Serpentine Belt Wrench (Blue-Point )
• 6ʺ long adaptor with 1/2ʺ male square • Used to release any serpentine belt tensioner with a 1/2ʺ
• Female triple square drive allows more flexibility to work square drive opening
around obstacles by coming in at different angles with a • Ratcheting action allows better positioning of the
1/2ʺ breaker bar tool, creating a greater swing angle than a solid-type
®
• Similar to the Snap-on 6ʺ torque adaptors but with a serpentine belt wrench
male square • Reversible ratchet head is only 1ʺ thick so it will fit
®
• If using with a torque wrench, refer to the Snap-on between the tensioner face and fan blades on S Series
®
®
SS306G Torque Chart for the formula to obtain the 60 Detroit Diesel and some Caterpillar engines
correct applied torque • Also ideal for working on buses and delivery vans where
Heavy-Duty Applications: the doghouse or engine shrouding restrict access
• For serpentine belt tensioners with a 1/2ʺ square • Compact overall length keeps handle from coming in
®
drive opening found on Series 60 Detroit Diesel and contact with radiator hoses, charged air cooler pipes,
®
Caterpillar engines hydraulic lines or frame rails
• Other applications include buses and delivery vans • Vinyl grip for comfort
where the doghouse or engine shrouding can get in the • 13ʺ overall length
way and make the work area very tight
Automotive Applications:
®
®
• 1/2ʺ serpentine belt tensioners on Dodge /Chrysler
®
®
®
(2.0 L and 3.0 L engines) Ford , Lincoln and Mercury
®
(2.3 L, 3.0 L, 4.2 L and 4.6 L engines) GM (2.5 L, 4.7 L,
5.0 L and 5.7 L engines) vehicles
®
Ford ICP Sensor Socket
S6196KR 3/8ʺ Square Drive 6-Point ICP Sensor Socket for Ford Vehicles
®
®
• Easily removes and installs the ICP Sensor on 2002 and 2003 Ford 6.0 L diesel
truck engines
• Spring retention securely holds the sensor during use
• Manufactured from the highest quality proprietary steel, providing optimum
S6196KR strength and durability
®
• 6-point configuration and Flank Drive wrenching system
• Nickel-chrome finish resists against rust and corrosion
®
®
• Snap-on sockets using the Flank Drive wrenching system grip the fastener on
the flanks/flats, delivering 15–25% more turning power
Glow Plug Tool
FGPT Glow Plug Harness Tool
• Prevents damage to the harness and connector rail
FGPT • Removes and installs glow plug connectors
482 • Orange color for easy identification in dark engine compartments
Snapon.com 1.877.762.7664
