DIESEL TOOLS

Feeler Gauges
®
FB325A ‡ SAE and Metric Feeler Gauge Set (Blue-Point )
• Includes blade sizes .0015 and .002–.025ʺ
• Use for adjusting governor gap FB308D
• Double stamped with SAE and metric sizes
®
FB308D ‡ Step Feeler Gauge Set and Holder (Blue-Point )
• Used for adjusting valves GENERAL
• Includes 12 step blades in sizes .008ʺ/.010ʺ–.028ʺ/.030ʺ
®
FB328A ‡ Step Feeler Gauge Set and Holder (Blue-Point ) FB325A
• For adjusting valves
• Includes two step blades: .011ʺ/.013ʺ and .013ʺ/.015ʺ
®
• For valve adjustment on GM 8.2L engines
• Double stamped with SAE and metric size FB328A

Push Rod Wrenches
M3517B M3518
M3517B Push Rod Lock Nut Wrench
• 1/2ʺ open end, 102° offset handle
M3518 Push Rod Adjusting Wrench HAND
• 5/16ʺ open end, 102° offset handle

M3525A M3503B S6200 FLS1219 TOOLS

Special Application Sockets
M3525A 1/2ʺ Drive Spanner Socket FLS1219 1/2ʺ Drive Fuel Line Socket
• 1/2ʺ drive, 3-7/32ʺ long • Designed to easily torque fuel injector lines correctly,
• Includes 1-1/8ʺ internal hex for use on “Fuel Squeezer” reducing or eliminating the possibility of a fuel leak or
Series engines damaging the line, fuel rail or fittings
M3503B 3/8ʺ Drive Fuel Line Nut Socket • Easily applies the 30 ft-lb factory-required torque
• 1/2ʺ wrench opening • No torque adaptors with complicated
• 3/8ʺ drive, 6-point calculations required
®
• Shaped for access to fuel line nuts • Use on Cummins ISB engines 1998 to present
• 3-1/4ʺ long • 1/2ʺ drive, 19 mm
• Additional applications include the head temperature FLS1222 1/2ʺ Drive Fuel Line Socket
®
sensor on Buell Motorcycles • Designed to easily torque fuel injector lines correctly,
S6200 1/2ʺ Drive 12-Point Metric 12 mm Engine reducing or eliminating the possibility of a fuel leak or
Bearing Cap Bolt Impact Socket damaging the line, fuel rail or fittings
• Use to service engine cam bearing cap bolts on both • Easily applies 80 ft-lb factory-required torque
older and newer generation Detroit Diesel engines • No torque adaptors with complicated
®
• Newer generation Detroit Diesel engines use longer calculations required
®
®
cam bolts than earlier generation engines • Use on Cummins ISX engines 2007 to present
• The S6200 is specially designed to work on both • 1/2ʺ drive, 22 mm
®
®
engine generations TLEPL50 1/4ʺ Drive TORX Plus 5EPL Socket
• 4-3/8ʺ long • Manufactured from special steel with higher
alloy content
• Precision forged and heat treated for optimum strength
and durability
• Nickel-chrome plating helps protect against corrosion
and makes it easy to wipe clean
• Do not use chrome or industrial finish hand tools with impact drivers
• Do not use “cheater bars” on handles 481
• ‡ These products can expose you to chemicals which are known to the state of California to cause
cancer and reproductive harm. See pages 906-907 for details.
• Read safety precautions on pages W1 to W4
