DIESEL: DIESEL SERVICE SETS

Diesel Timing Gauge Set
SP500 ‡ Diesel Timing Gauge Set SP5001 ‡ Dial Indicator (Blue-Point )
®
®
(Blue-Point ) • Features rack and pinion construction
• Used to update existing 2017DSP • Refer to the pump manufacturer’s
diesel service sets to handle 1994– service manual when using
1998 Cummins B engines used in this gauge SP500
®
®
®
Dodge Ram 250/350 pickup trucks • Gauge diameter is 2-1/4ʺ GENERAL
®
and some Ford trucks • Range is 30 mm
®
SP503 ‡ Spline Socket (Blue-Point ) • Gauge is marked in .01 mm
increments
• Used to remove and replace the ®
delivery valve on most Bosch fuel SP5002 ‡ Gauge Holder (Blue-Point ) SP503 SP504
®
injection pumps • Used in the fuel injection pump in
®
SP504 Gear Puller (Blue-Point ) place of the #1 delivery valve to
• Used to remove the injection locate the base circle of the
pump gear injection pump cam
• Bolt thread is M8 x 1.25 • Male thread is M22 x 1.5 SP5002
• Bolt length is 44 mm
DIESEL: SERVICE TOOLS FOR CUMMINS ENGINES
®
Pulley Installers and Pullers
M1324 Pulley Installer CJ86-1 Yoke
• For installing the accessory drive • Included with the CJ2002 HAND
pulley on the shaft Gear Puller Set
• Includes 7/8ʺ-14 NC threaded • 1-3/4–4-1/2ʺ
adaptor, washer type bearing and CJ83-3 Pressure Screw
installer housing • 3/4–16 x 5-1/8ʺ M1324
CJ83C Pulley and Gear Puller CJ66-15-3 Centering Point
• Ideal for servicing crankshaft pulleys, • 5/8ʺ head, 90° outward point
gears and timing gears on a wide ME5A54 Washer
range of gasoline and diesel engines, ME5A55 Washer
®
including Cummins accessory drives CJ83C
and water pumps ME3A45 Stud
• Includes (2) 3/8ʺ-16 x 3ʺ, 5/16ʺ-18 x ME3A44 Bolt
2-1/2ʺ and M10-1.5 x 65 mm bolts ME3A75 Stud
• Nominal capacity is 3-1/2 ton TOOLS
Torque Adaptor Set
M1302A5 Screwdriver ST669-1 Handle Assembly
• 1/2 x .062ʺ screwdriver • Included in the ST669 M1302B18 M1302B24
M1302B18 12-Point Deep Socket Torque Adaptor Set
• 9/16ʺ deep, 12-point socket TM82 1/4ʺ Drive 1/4ʺ Flat
M1302B24 12-Point Deep Socket Tip Short Bit Socket
• 3/4ʺ deep, 12-point socket • Manufactured from
ST669 6 pc Torque Adaptor Set high-grade alloy steel ST669
• Used to loosen and adjust lock nuts
to manufacturing specifications

Compression Adaptors/Injector Style
M3540C‡ Compression Adaptor
®
3
• For Cummins 855 in NH, and 903 V8 and L10 diesel engines M3540C M3585C
M3585C Compression Adaptor
®
®
• For Case /Cummins Series C 8.3 L engines
M3584C‡ Compression Adaptor
®
• For Case /Cummins Series B 2.9 L, 3.9 L and 5.9 L diesel engines M3584C
®
Injector Brushes
®
MB5D Bronze Injector Brush (Blue-Point )
• Bronze non-abrasive brush cleans carbon from injector tips
MB6BTA 9ʺ Injector Brush (Blue-Point ) MB5D
®
• Stainless steel wire brush cleans the injector cavity in the cylinder head
• 9ʺ long MB6BTA
