TOOLS DIESEL TOOLS Oil Rail Gauge ®

ORG1315 Oil Rail Gauge
• Correctly determine dimension and select correct back-up ring when installing
high-pressure oil manifolds
• Used to install high-pressure oil manifolds on International DT466 and
MaxxForce engines from 2004–2013
®
• All three sizes in one tool
ORG1315
• No stacking of feeler gauges
• Heat treated 4130 for durability and accuracy
• Red vinyl-dipped handle for increased visibility
• Large ring end for easy handling
HAND FDT1116 M3530 M3531

Fuel Line Disconnect Tools
• This set includes a total of four fuel line disconnect tools: Governor Gap Wrenches

M3530 Governor Gap Adjusting Wrench
–two tools—a straight and a 90° angle—for the 11.8 mm • 3/8ʺ open ends, 4ʺ long
GENERAL
fuel lines and; –two tools—a straight and a 90° angle— • Special thin design with 30° and 60° angle heads
for the 16 mm fuel lines M3531 Governor Gap Lock Nut Wrench
• The OEM tool sets ZTSE4773 and ZTSE4772 do NOT • 7/16ʺ open ends and is 4-1/4ʺ long
include the straight tools—the straight tools allow • Special thin design with 30° and 60° angle heads
access into tight areas
• All four tool handles are highly visible orange for
easy identification
FDT11 Angled Fuel Disconnect Tool
• 90° angle for 11.8 mm fuel lines
• Handle is highly visible orange for easy identification B4400A
FDT11STR Straight Fuel Disconnect Tool
• For 11.8 mm fuel lines
• The OEM tool sets ZTSE4773 and ZTSE4772 do NOT WSW3
include the straight tools the straight tools allow access
into tight areas
• Handle is highly visible orange for easy identification Starter Bolt and Fuel Filter Wrenches
FDT16 Angled Fuel Disconnect Tool WSW3 Duramax Fuel Filter Water Sensor Wrench
®
• 90° angle for 16 mm fuel lines • Glass-filled nylon tool with four sizes: 40, 41, 42
• Handle is highly visible orange for easy identification and 46 mm
FDT16STR Straight Fuel Disconnect Tool • All-in-one tool that works on all four OEM and
• For 16 mm fuel lines aftermarket sizes available in the marketplace today
®
• The OEM tool sets ZTSE4773 and ZTSE4772 do NOT • Applications: 6.6L Duramax Diesel engines including
®
®
®
®
include the straight tools the straight tools allow access 2001–current Chevy Silverado and GMC Sierra 2500
into tight areas and 3500 vehicles
• Handle is highly visible orange for easy identification B4400A Starter Bolt Wrench
FDT1116 Fuel Line Disconnect Tool Set • Manufactured from special alloy steel and heat treated
• Includes (4) fuel line disconnect tools—a straight and a for optimum strength
90º angle for the 11.8 mm fuel lines and a straight and a • Specially contoured for tight-access areas
®
90º angle for the 16 mm fuel lines • Used for John Deere starter bolts
• OEM tool sets ZTSE4773 and ZTSE4772 do NOT include
the straight tools—the straight tools allow access into
tight areas
• All four tool handles are highly visible orange for
easy identification
• Set includes FDT11, FDT11STR, FDT16 and FDT16STR
Fan Clutch Wrench
®
FCT706 Fan Clutch Wrench (Blue-Point )
• Used for heavy-duty truck engines
• Hole pattern on the tool aligns with fasteners on
the fan hub
FCT706 • Use with open end to remove a fan clutch
• 24-1/2ʺ length for maximum leverage
480
Snapon.com 1.877.762.7664
