DIESEL TOOLS

Injector Pump Idle Lock Nut Wrenches
®
SP144 Injection Pump Wrench (Blue-Point )
• 13 mm, 12-point box wrench is used to service the injection pump mounting
®
bolts found on 5.9 L Cummins engines
Engine Turning Tools GENERAL
®
YA9565A Engine Turning Tool (Blue-Point )
• Used to rotate the engine for making valve and injection pump adjustments SP144
on Cummins and Case 3.9 L, 5.9 L and 8.3 L B and C Series engines
®
®

Injector Height Gauges
• Used to set injectors during installation and at set service intervals SP7882
• Knurled handle screws into the gauge at a 90° angle for work in close quarters
SP7882 6 pc Diesel Injector Height Gauge Set
• Five-in-one gauge set covers all applications for Detroit Diesel 50 and SP7882-1
®
60 Series engines
• Includes (5) injector height gauges and (1) handle
• Includes a storage pouch
SP7882-1 Diesel Injector Height Gauge Handle HAND
SP7882-782 Injector Height Gauge (Blue-Point )
®
®
SP7882-788 Injector Height Gauge (Blue-Point ) SP7882-803
SP7882-803 Injector Height Gauge (Blue-Point ) SP7882-782 SP7882-788
®
®
SP7882-810 Injector Height Gauge (Blue-Point )
®
SP7882-821 Injector Height Gauge (Blue-Point )
SP7882-810 SP7882-821
Diesel Fuel System Tools
®
FPWD14 Duramax Fuel Pressure Sensor Wrench
• Saves hours of time by eliminating the need to remove the EGR cooler system and fuel TOOLS
rail—simply unbolt air conditioning compressor to remove the front EGR valve
• 2 pc design reduces the time required to service the fuel pressure release valve
• Tool slips onto the release valve from back to front allowing the handle to slide into the FPWD14
crescent end of the socket, making loosening the fuel pressure release valve easier

®
Ford Fuel Filter Wrench
®
FFW2A 24/36 mm Fuel Filter Socket (Blue-Point )
• Double-sided 3/8ʺ drive socket includes both a 24 mm 6-point socket and a 36 mm
slotted socket
• Made of machined aluminum and anodized for surface protection
FFW2A

Hand Sockets
HXD22 1/2ʺ Drive External Hex 22 mm Socket
• Essential for removing motorcycle front wheels
• Use torque wrench for axle torque specs
• Use breaker bar to remove difficult fasteners
HXD22
Hand Sockets
HXD24 1/2ʺ Drive External Hex 24 mm Socket
• Essential for removing motorcycle front wheels
• Use torque wrench for axle torque specs
• Use breaker bar to remove difficult fasteners
®
• Applications: Suzuki motorcycles (1300GSXR and 1000GSXR); Hayabusa
®
motorcycles (various models)
HXD24
• Screen the puller application
• Inspect the puller, do not use damaged parts 479
• Use the proper type and size puller for the job
• Do not use chrome or industrial finish tools with impact drivers
• Read safety precautions on pages W1 to W4
