TOOLS PULLERS: BLIND HOLE BEARING 3 1/4ʺ Spread Yoke Thread Size Thread Size

Internal
External
Stock No.
Description
—
—
Pressure Screw
CG40-1
—
—
15/16ʺ Nut
CG40-2
—
—
CG40-3
Expanding Rod
5/8–18
3/8–24
CG41-11
1/4–5/16ʺ Collet
—
—
CG41-14
5/16–3/8ʺ Collet
—
—
CG41-12
—
3/8–7/16ʺ Collet
—
CG41-13
CG40-4 1/2–20 Expanding Rod 5/8–18 1/2–20
CG40-9 7/16–1/2ʺ Collet — —
HAND CG40CB CG40CB 14 pc Blind Hole Bearing Puller Set — —
1/2ʺ–5/8ʺ Collet
—
—
CG40-15
5/8–3/4ʺ Collet
—
—
CG40A6
3/4–7/8ʺ Collet
CG40-7
—
7/8–1ʺ Collet
—
CG40-8
—
1–1-1/8ʺ Collet
—
CG40A10
• 14 pc collets, yoke, pressure screw and expanding rods
• Range 1/4–1-1/8ʺ
• Includes a storage box
GENERAL
Internal External
Stock No. Description
Thread Size Thread Size
CG270-1A Pressure Screw — —
CG45-2 1-1/8ʺ Wrench Size Thrust Nut — —
CG45-3 5-3/4ʺ spread Yoke — —
CG45-4 Expanding Rod 3/4–16 5/8–18
CG45-15 1–1-1/4ʺ Collet — —
CG45-6 1-1/4–1-1/2ʺ — —
CG45-7 1-1/2–1-3/4ʺ (Uses CG45-4 Expanding Rod) Collet — —
CG45 7 pc Blind Hole Bearing Puller Set
CG45
• Includes 7 pc (1–1-3/4ʺ) collets, yoke, slide screw and slide hammer
Internal External
Stock No. Description
Thread Size Thread Size
CG250-8A 5/8ʺ-18 UNF x 18 9/16ʺ Slide Screw — —
CG250-9 2 lb Slide Hammer — —
CG40-1 Pressure Screw — —
CG40-2 15/16ʺ Nut — —
CG40-3 3 1/4ʺ Spread Yoke — —
CG41-11 Expanding Rod 5/8–18 3/8–24
CG41-14 1/4–5/16ʺ Collet — —
CG41-12 5/16–3/8ʺ Collet — —
CG41-13 3/8–7/16ʺ Collet — —
CG40-4 1/2–20 Expanding Rod 5/8–18 1/2–20
CG40-9 7/16–1/2ʺ Collet — —
CG40-15 1/2ʺ–5/8ʺ Collet — —
CG2545AB CG40A6 5/8–3/4ʺ Collet — —
CG40-7 3/4–7/8ʺ Collet — —
CG40-8 7/8–1ʺ Collet — —
CG40A10 1–1-1/8ʺ Collet — —
CG270-1A Pressure Screw — —
CG45-2 1-1/8ʺ Wrench Size Thrust Nut — —
CG45-3 5-3/4ʺ Spread Yoke — —
CG45-4 Expanding Rod 3/4–16 5/8–18
CG45-15 1–1-1/4ʺ Collet — —
CG45-6 1-1/4–1-1/2ʺ — —
CG45-7 1-1/2–1-3/4ʺ (Uses CG45-4 Expanding Rod) Collet — —
CG2545AB 25 pc Blind Hole Bearing Puller Set
474 • Includes 25 pc collets, yokes, slide screw and slide hammer
