PULLERS: HYDRAULIC POWER UNITS

Pump and Ram Set Components
Features of two-stage hydraulic pumps:
• Two stage design will advance 20–50 ton rams in the low pressure CG420-1A
stage in less than 1/3 the strokes required on other models
• CG520 Ram extends in 60–70 strokes CG650
• CG420 Ram extends in 17–19 strokes
• When high pressure is required, the low-pressure stage automatically
kicks out to leave the high-pressure stage to do the work CG720 GENERAL
Collapsed Height, Extended Height, Effective Area Pressure Screw Size,
Capacity, tons Stock No. Stroke, inches Oil Capacity (in )
3
inches inches (piston) inches
6 CG650 1-1/2 4-11/16 6-3/16 1.473 2.210 5/8–11 x 13-1/4
10 CG120 1 4-3/4 5-3/4 2.440 2.440 3/4–10 x 16-1/4
20 CG420-1A 2 6 8 4.418 8.836 1-1/8–8 x 20-1/2
35 CG720 2-1/2 7 9-1/2 7.903 19.758 1-3/8–8 x 25
50 CG520 3 8-1/8 11-1/8 11.066 33.198 1-5/8–5-1/2 x 30
CG222 4-Ton Hydraulic Pump and Ram Set CG122 10-Ton Hydraulic Pump and Ram Set
Includes: Includes:
CG4-2A Single Stage Pump CG120 Ram, Hydraulic, 10-Ton
CG120-3-1 Hydraulic Hose CG4-2A Single Stage Pump
CG120-4 Coupler Set CG120-13 Pressure Screw
CG220 4 Ton Hydraulic Ram CG120-3-1 Hydraulic Hose CG4-2A
CG220-13 Pressure Screw CG120-4 Coupler Set HAND
CG4-2A Single Stage Pump
CG652 6-Ton Hydraulic Pump and Ram Set CG420A 20-Ton Hydraulic Pump and Ram Set
Includes: Includes:
CG120-3-1 Hydraulic Hose CG420-1A 20-Ton Ram
CG120-4 Coupler Set CG420-2A Single Stage Hydraulic Pump
CG250-20 Replacement for CG250 CG420-1-14 Centering Adaptor CG420-2A
Series Point CG420-3-1 Hose
CG4-2A Single Stage Pump CG420-4 Coupler Set
CG650 6-Ton Ram CG420A2S Hydraulic Pump and Ram Set TOOLS

HYDRAULIC ACCESSORIES

CG6223 Hydraulic Conversion Power Kit
• 6 ton
• Converts the CG250, CG253 manual pullers and
CG1500 puller set to hydraulic power
• Includes 6 ton pump and ram set, two jaw yoke,
hand wheel adaptor and three jaw yoke
CG652 6-Ton Hydraulic Pump and Ram Set
CG250-15 6-Ton Yoke CG1224 CG420-5C CG420-6
CG250-16 Hand Wheel Adaptor
CG253-15 6-Ton Yoke
CG1224 10-Ton Hydraulic Conversion Kit
• Converts the CG270, CG273, CG280, and CG283
manual pullers (on tool control panel A) and CG1700/ CG558
CG2500B puller sets to hydraulic power
CG122 10-Ton Hydraulic Pump and Ram Set
CG270-15 10-Ton Yoke
CG270-16 Hand Wheel Adaptor CG420-5C Pressure Gauge
CG273-15 10-Ton Yoke • Can be used with 6-, 10-, 20-, 35- and 50-ton hydraulic
equipment
CG558 50 Ton Hydraulic Push-Pull Puller • Use for CG4-2A, CG420-2A and CG420A-2S hydraulic pumps
Accessory Set • Indicates hydraulic pressure in ton of pressure as well as PSI
• Includes additional side rods and end blocks, • Adaptor CG420-6 is required to attach gauge to pumps
plus work screw, side rod, and bull nose adaptors CG420-6 Gauge Mounting Adaptor
to increase the versatility of the CG555 basic • Mounts CG420-5C Pressure Gauge to 6, 10, 20, 35 and 50 ton
hydraulic set hydraulic systems
