TOOLS PULLERS: INDUSTRIAL

HAND Industrial Puller Sets CG1038KA

CG1038KA Industrial Puller Set
• Includes the CG1038KA industrial puller set and the CG1224 power
• Includes more than 35 basic pullers that
kit for converting 10-ton manual pullers to hydraulic power; CG300-
will assemble into more than 165
1, CG305-8 and CG350-1 pressure screws; CG343-1 4ʺ plug; CG350-2
puller combinations CG1050KA Expanded Industrial Puller Set
GENERAL
• Standard pullers in this set have a range from manual yoke for converting the 20-ton hydraulic pullers to manual
2–20-ton power and CG555 basic hydraulic set for building a 50-ton hydraulic
• The hydraulic power components provide up bar type puller
to 20-tons of easy pulling power • Includes CG420-5C pressure gauge, CG420-6 gauge mounting
• Optional 10 and 50-ton hydraulic accessories adaptor, ten CG250-20 small centering adaptors and ten CG270-20
are available large centering adaptors
• Components are mounted on (4) 24 x 32 x 3/4ʺ KRA213E A-Frame
tool control panels (labeled A, B, C and D) with • Mobile unit features 23,220 in , 1,260 in of storage for convenient
2
3
white silhouettes access and orderly storage
• The panels are mounted on KRA213E A-frame • Measures 26-1/2 x 52-3/8 x 32-3/8ʺ
Tool Control Boards
VE113B Tool Control Board
• Panel A is designed to hold the components for the CG2500CS interchangeable puller set (6, 7-1/2, 10 and
12-1/2 ton capacity)
• Also used as the tool control board for the CG2500CSB manual puller set
CGJ250 6-Ton Two Jaw Pressure Screw Puller CG270HA 10-Ton Two Jaw Slide Hammer Puller
CG250HA 6-Ton Two Jaw Slide Hammer Puller CG270SA 10-Ton Two Jaw Pressure Screw Puller
CG250HLA 6-Ton Two Jaw Slide Hammer Puller CGJ273 12-1/2-Ton Three Jaw Pressure Screw Puller
CG253A 7-1/2-Ton Three Jaw Pressure Screw Puller CG273HA 12-1/2-Ton Three Jaw Slide Hammer Puller
CG253HA Three Jaw Medium Duty Puller CG280A 10-Ton Two Jaw Pressure Screw Puller
CGJ270 10-Ton Two Jaw Pressure Screw Puller CG283A 12-1/2-Ton Three Jaw Pressure Screw Puller

VE138-3B Tool Control Board
• Panel B is designed to hold the CG2400B light duty puller set, CJ840C tapped hole puller
set, CJ949 bearing separator and CJ9500 bearing separator set components
CG240A 2-Ton Two Jaw Pressure Screw Puller CJ949 1-1/8ʺ Bearing Separator
CG240HA 2-Ton Two Jaw Slide Hammer Puller CJ950 2-3/8ʺ Bearing Separator
CG243A 2-1/2-Ton Three Jaw Pressure Screw Puller CJ951 4-1/2ʺ Bearing Separator
CG243HA 2-1/2-Ton Three Jaw Slide Hammer Puller CJ952 6-1/8ʺ Bearing Separator
CJ93B Puller Set with Small Slide Hammer
CJ840C Complete Bar-Type Manual Tapped Hole Puller Set
VE138-2B Tool Control Board VE138-1B Tool Control Board
• Panel C is designed to hold the CG450HYA 20 ton • Panel D is designed to hold components of the CG400
hydraulic bar type puller components and the 20 ton jaw type puller, three CG305-9 long jaws, CG455
components of CG2545AB blind hole bearing puller set and CG455A threaded adaptor sets, plus CG455-18 and
CG45 7 pc Blind Hole Bearing Puller Set CG455-19 pressure screw adaptors
CG450 Bar-Type Manual Puller Set • The adaptors are for use with the bar-type pullers on tool
CG450HYA Bar-Type Hydraulic/Manual Puller Set control panel C
CG400 Manual Combination Two and Three Jaw Puller
CG400HYA 20-Ton Hydraulic Puller
468 CG405 Manual Combination Two and Three Jaw Puller
CG405HYA 20-Ton Hydraulic Puller
Snapon.com 1.877.762.7664
