PULLERS: AUTOMOTIVE

Pitman Arm Pullers
CJ89 Pitman Arm Puller
CJ115 Pitman Arm Puller
• Similar in design to CJ119B except it is designed for compact and
intermediate size cars
CJ119B Pitman Arm Puller (Domestic Cars/Light Trucks)
• Designed for most US cars and light trucks CJ89
• Pressure screw size: 3/4ʺ-16 x 6-7/8ʺ GENERAL
• Industrial finish
YA6880 Low-Profile Pitman Arm Puller
®
• Fits in the confined space on most GM (1988–2000 C and K Series
chassis) trucks and SUVs; also fits 2001–present trucks and SUVs with
steering gear box/pitman arms
• Forged chromoly steel for strength and durability
• Design allows the technician save time removing the arm off of the CJ119B
steering gear box without altering the boxes position
PAR1188 Heavy-Duty Pitman Arm Puller
• Removal of large pitman arms onto 1 ton pickup trucks YA6880
®
• Applications include Ford F-250/350 (2000–later), Dodge 2500/3500
®
(2011–later), Chevrolet /GMC 2500/3500 (2011–later)
®
®
PAR1490 Super Duty Pitman Arm Popper
• Fits short sector shaft and long sector shafts with a bolt or nut attachment
• Forged from alloy steel
• Heat treated for rigidity and durability HAND
• Fine pitch thread for reduced effort PAR1490
• Ball bearing tip to protect the sector shaft
GENERAL PURPOSE INTERCHANGEABLE

Light-Duty Pullers
Builds pullers.
Maximum Reach, Outside Spread, Inside Spread,
Stock No. Puller Type
inches (mm) inches inches
CG240 2-Jaw 2-1/2 (64) 0–3 7/8–3-1/4
CG240H 2-Jaw 2-1/2 (63) 0–3 7/8–3-1/4 TOOLS
CG240HL 2-Jaw 3-1/2 (88) 0–4 1–3-3/4
CG240L 2-Jaw 3-1/2 (89) 0–4 1–3-3/4
CG243 3-Jaw 2-1/2 (64) 0–3 7/8–3-1/4
CG243H 3-Jaw 2-1/2 (64) 0–3 7/8–3-1/4
CG243HL 3-Jaw 3-1/2 (89) 0–4 1–3-3/4
CG243L 3-Jaw 3-1/2 (89) 0–4 1–3-3/4
CG2400B Manual Light-Duty Interchangeable General Purpose Puller Set
• This versatile set provides two- or • Interchange parts to build any of the
three-jaw pulling with pressure screw four puller combinations CG2400B
or slide hammer options • Up to 2-1/2 ton of pulling power
• 3ʺ dia. capacity for outside pulls
Medium-Duty
Builds pullers. Medium-duty pullers Set converts CG250 and CG253 manual
deliver up to 7-1/2 ton of pulling power, pullers to hydraulic power. The manual
4-1/2ʺ dia. capacity for outside pulls components of the indicated medium
and from 3/4–8ʺ dia. capacity for inside duty pullers are included in the heavy-
pulls. CG6223 Hydraulic Conversion duty (CG2500/CG2510 Series) sets.
Maximum Reach, Outside Spread, Inside Spread,
Stock No. Puller Type
inches inches inches
CG250 Two-Jaw 3 0–4-1/2 1-1/2–3-1/2
CG250A Two-Jaw, Pulling Plate 3 0–4-1/2 1-1/2–3-1/2
CG250H Two-Jaw 3 0–4-1/2 1-1/2–3-1/2
CG250HL Long Jaw, Two-Jaw 6 0–8-1/2 3/4–8
CG253 Three-Jaw 3 0–4-1/2 1-1/2–3-1/2
CG250
CG253H Three-Jaw 3 0–4-1/2 1-1/2–3-1/2
CG253L Three-Jaw 6 0–8-1/2 3/4–8
• Screen puller application
• Inspect the puller, do not use damaged parts
• Use the proper type and size puller for the job 463
• ‡ These products can expose you to chemicals which are known to the state of California to cause
cancer and reproductive harm. See pages 906-907 for details.
• Read safety precautions on pages W1 to W4
