PULLERS: BAR-TYPE INTERCHANGEABLE
TOOLS

CJ Interchangeable Pullers— Key No. Stock No. CJ86-1 Set CJ83C CJ82B CJ81D CJ85A CJ80A
HAND A Yoke A1 CJ100-1 Usable Range, inches Pin Holes per Side • • • • •
Major Components
Contains:
Component
Specific Dimensions
4
10-1/2–16
Yoke
3
6–10-1/2
A2
CJ118-1
3
A3
3–6-1/2
Yoke
CJ85-1
2
1-3/4–4-1/2
A4
Yoke
CJ86-1
Hex Size, inches
Thread x Length
B
3/4-16 x 10-1/2
Pressure Screw
7/8
Pressure Screw
B2
CJ83-2
3/4-16 x 5-1/8
Pressure Screw B1 CJ105-3 3/4-16 x 6-11/16 7/8 • • • • •
B3
7/8
CJ83-3
C Head Dia., inches Point Type
GENERAL
Point C1 CJ66-15-3 5/8 90° Outward • • • • •
Point C2 CJ84-16 7/8 90° Outward
D Maximum Reach,
inches
Jaws (2 needed) D1 CJ116-1 8-1/4 —
Jaws (2 needed) D2 CJ282-1 4-3/8 —
Jaws (2 needed) D3 CJ81-2A 1-3/8 — • • •
Jaws (2 needed) D4 CJ85-2 1-3/4 — •
Jaws (2 needed) D5 CJ87-1 1-3/8 — •
E Maximum Length,
inches
Clamp Bolts E1 CJ100A2 18 —
Clamp Bolts E2 CJ118-2A 11-1/2 —
Clamp Bolts E3 CJ85-3A 7-1/2 — • •
Clamp Bolts E4 CJ86-4A 5 — • •
F Inside Dia., inches Outside Dia., inches
Washer F1
(2 needed) CJ85-4 15/32 7/8 • • • •
Washer F2 ME5A54
(1 needed) 11/32 3/4 •
Washer F3
(1 needed) ME5A55 9/32 3/4 •
G Thread Size
Clamp Nuts G1
(2 Needed) ME4A33 7/16 x 20 — • • • •
H Diameter, inches Length, inches
Jaw Pins H1
(2 needed) CJ105-11 5/16 1-15/32 • • • •
J Outside Dia., inches Step Diameter, inches
CJ81B1A 1-1/2 1-1/8 •
CJ81B2A 1-5/8 1-1/4 •
Adaptors (Set of 4) J1
CJ81D1A 1-3/4 1-1/8 •
CJ81D2A 1-11/32 15/16 •
CJ85-5 2 1-1/2 •
CJ85-6 2-1/8 1-21/32 •
Adaptors (Set of 4) J2
CJ85-7 2-1/2 1-27/32 •
CJ85-8 3-1/16 2-3/8 •
K Thread x Length
Studs (2 needed) K1 ME3A44 3/4-16 x 3 — •
Studs (2 needed) K2 ME3A45 5/16-18 x 2-1/2 — •
Studs (2 needed) K3 ME3A75 M10-1.5 x 65 mm — •
Letters in chart refer to Key No. in chart below (A3, B1, C1, etc.)
