PULLERS: AUTOMOTIVE Power Steering and Alternator Pullers/Master Set
TOOLS CJ132A ‡ 14 pc Puller and Power Steering Pump/Alternator Pulley

Installation/Removal Set (Blue-Point )
®
®
®
®
• GM Quad 4, 3.1 L GM and 4.6 L Ford applications
• Removes/installs press-on, belt-driven accessory pulleys
• Removal housing for grooved hub diameters of 1-1/8, 1-5/16 and 1-3/8ʺ
• Includes components for a 3/8ʺ-16 threaded shaft
• Housing holding bar prevents the main housing from spinning during use
with an impact wrench
• Quad 4 installation nut simplifies usage with 4-cylinder GM vehicles
• Includes instructions and a carrying case ®
CJ132-1 Pulley Tool (Blue-Point ) ®
®
HAND CJ132-4 ‡ Quad 4 Removal Pin (Blue-Point ) ® ®
CJ132-2 ‡ Sleeve (Blue-Point )
®
CJ132-3 Installation Nut (Blue-Point )
®
CJ132-5 ‡ Quad 4 Installer (Blue-Point )
®
CJ132-6‡ 3.1L Installer for GM Vehicles (Blue-Point )
®
®
CJ132-7 ‡ 3/8ʺ-16 Installer (Blue-Point )
®
CJ132-8 ‡ 4.6 L Installer for Ford Vehicles
CJ1329 ‡ Universal Removal Pin (Blue-Point )
CJ13210 ‡ Housing Holding Bar (Blue-Point )
CJ132A
CJ13211 Quad 4 Installation Nut (Blue-Point )
CJ13212 Threaded Shaft (Blue-Point ) ® ®
®
GENERAL
®
CJ13213 Removal Housing (Blue-Point )
CJ13214 Bearing (Blue-Point )
®
®
CJ13215 Washer (Blue-Point )
CJ132AIS Instruction Sheet (Blue-Point )
®
Harmonic Damper Pulley Pullers
CJ146 Crankshaft Harmonic Balancer Kit
• Remove the crankshaft harmonic balancer on 1990 and later 3.3 L and 3.8 L
GM engines
®
• Shoulder bolt adaptors provide the correct installation depth, preventing
CJ146 damage to the crank sensor and interrupter rings
• Includes (3) CJ146-1 adaptors, (1) CJ146-2 extension and vinyl storage pouch
®
• Requires Snap-on CJ98-1 yoke and CJ83-3 pressure screw for use (not included)
YA6490A Harmonic Damper Pulley Puller (Blue-Point )
®
• New spring-loaded legs allow for leg position retention
• Provides greater ease and control when installing the puller in confined areas
• Removes harmonic damper pulleys found on many Chrysler and GM engines
®
®
• Used on autos, pickups, SUVs and vans
®
YA13350 Harmonic Dampener Pulley Puller (Blue-Point )
®
• Use on 3.6L Camaro engines
• Unique design accesses the pulley on internal pulley ledges
®
YA13450 Harmonic Dampener Pulley Puller (Blue-Point )
®
• Use on 3.5 L and 5.7 L Dodge engines
YA6490A
• Unique design accesses pulley on internal pulley ledges
Harmonic Balancer
®
YA6491A Harmonic Damper Pulley Puller Update Kit (Blue-Point )
• Updates earlier YA9740 pullers to the same applications as the new YA6490A
• Kit updates other pulley pullers that are similar to the YA9740 series of pullers
• Add YA6491 Update Kit to the existing YA9740 series pullers to add these new
®
®
®
®
applications: GM 4.2 L Straight 6-cylinder; Chevy Trailblazer . Colorado ;
®
®
®
GMC Envoy , Canyon (2004–later); Oldsmobile Bravada (2003–later);
®
®
®
®
Buick Rainier (2004–later) 3.5 L Straight 5-cylinder: Hummer H3
®
(2006–later) 2.8 L Straight 4-cylinder
YA6491A
®
YA9740A-6 Short Push Rod (Blue-Point )
• Short push rod for older model YA9740 pullers
462 • Use on crankshafts that are not drilled to full depth
