PULLERS: BAR-TYPE INTERCHANGEABLE
TOOLS Accessory Set CJ81B1A Adaptor CJ85-8 Adaptor

CJ2005 Master Interchangeable
Puller Set
CJ85-5 Adaptor
CJ81D2A Adaptor
• Includes all components for the
CJ85-6 Adaptor
CJ118-1 Yoke, 6–10-1/2ʺ
CJ2001, CJ2002, CJ2003A, CJ2004
CJ118-2A Clamp Bolt
CJ85-7 Adaptor
VE200A tool control board
CJ81D1A Adaptor
CJ2005 and CJ2005 puller sets on a CJ81B2A Adaptor CJ85-2 Jaw
HAND Stock No. Width, inches Length, inches Overall Length, Pressure Screws CJ83-9
CJ Bearing Adaptors
Swivel Head
Swivel Head
inches
CJ83-9 Pressure Screw
1.2
3.02
2.03
CJ127A
• Optional pressure screw for bar-style interchangeable pullers
1.2
3.15
2.31
CJ128A
• Applications include heavy-duty truck transmissions like
3.24
1.2
2.9
CJ137
®
Eaton transmissions found on Kenworth heavy-duty trucks
®
• Can also be used with the CJ2000A, CJ2000S, CJ2000SB,
CJ2002 and CJ2004 puller sets
• Thread: 3/4ʺ-16
• Length: 8-3/4ʺ
GENERAL
PULLERS: SPECIAL PURPOSE
Small Slide Hammer Puller Set
CJ93B Puller Set with Small Slide Hammer
• Removes bushings, seals, sleeves, bearings, bearing races, bronze and oilite
bushings and pressed-in studs
• Includes two sets of jaws, grease retainer adaptor, bearing hook, body dent
puller, stud-pulling head and 2 lb slide hammer
CJ93B • Thread size: 3/8-16ʺ
Small/Pilot/Ball Bearing Pullers
A78 Small Bearing Puller SP2031A ‡ Pilot Bearing Puller
®
• For bearings and bushings typically (Blue-Point )
found in small electric motors • Attaches to slide hammer shafts
• Includes a large jaw set for bronze and with 3/4ʺ-16 or 5/8ʺ-18 threads
oilite bushings, small jaw set for smaller • Pressure screw adaptor is made
bearings and bushings of stress-resistant steel
A78
• Up to 3 tons of pulling power • Industrial finish
• Working range is 1/2–2ʺ
SP2031A
Bearing Separators
For separating and pulling double
bearings and close-fitting gears. Use
with tapped hole, two-jaw pullers or
floor presses.
B Maximum B Minimum
Stock No. A C D
Spread Spread
CJ949 1-11/16 1-1/8 1/4 5/16ʺ-18 2-5/8
CJ950 2-3/8 2-3/8 3/8 3/8ʺ-16 3-3/4
CJ950 CJ952
CJ951 4-3/8 4-1/2 5/8 5/8ʺ-18 7-1/4
CJ952 5-7/8 6-1/8 1-1/2 5/8ʺ-18 9-5/16
CJ953 8-3/8 8-3/4 1-1/4 7/8ʺ-14 14-7/16
460

Snapon.com 1.877.762.7664
