PULLERS: 2-JAW PRESSURE SCREW

2-Ton Capacity (1.8 t), 2 Jaw
Maximum
Maximum Reach, Maximum Spread, Pressure Screw Jaw Thickness, Jaw Width,
Stock No. Spread, inches
inches (mm) inches (mm) inside Size, inches inches (mm) inches (mm)
(mm) outside
CG240A 2-1/2 (64) 7/8–3-1/4 (22–83) 3 (76) 3/8–16 x 5-1/16 3/16 (5) 3/8 (10)
CG240LA 3-1/2 (89) 7/8–3-3/4 (25–95) 4 (102) 3/8–16 x 6-1/16 3/16 (5) 3/8 (10)
6-Ton Capacity (5.4 t), 2-Jaw CG240A GENERAL
Maximum
Reach, Maximum Spread, inches Maximum Pressure Screw Jaw Jaw Width,
Stock No. Spread, inches Thickness,
inches (mm) inside Size, inches inches (mm)
(mm) (mm) outside inches (mm)
CGJ250 3 (76) 1-1/2–3-1/2 (38–89) 4-1/2 (114) 5/8–18 x 6-7/8 1/4 (6) 3/4 (19) CGJ250
CG250AA* 3 (76) 1-1/2–3-1/2 (38–89) 4-1/2 (114) 5/8–18 x 6-7/8 1/4 (6) 3/4 (19)
10-Ton Capacity (9.1 t), 2-Jaw
Maximum Jaw
Maximum Maximum Spread, inches Spread, Pressure Screw Thickness, Jaw Width,
Stock No. Reach, (mm) inside inches (mm) Size, inches inches inches (mm)
inches (mm)
outside (mm) CG270AA
CGJ270 5-1/2 (140) 2-1/2–7-1/2 (64–178) 8-1/2 (216) 3/4–16 x 9-13/16 1/4 (6) 15/16 (24)
CG270AA* 5-1/2 (140) 2-1/2–7-1/2 (64–178) 8-1/2 (216) 3/4–16 x 9-13/16 1/4 (6) 15/16 (24)
5-1/2 (140), 2-1/2–7-1/2 (64–178), 8-1/2 (216), 3/4–16 x 9-13/16,
CG272A** 1/4 (6) 15/16 (24) HAND
8-3/4 (222) 3–8 (76–203) 10 (254) 3/4–16 x 12-1/8
CG270SA 5-1/2 (140) 2-1/2–7-1/2 (64–178) 8-1/2 (216) 3/4–16 x 9-13/16 1/4 (6) 15/16 (24)
CG280A 8-3/4 (222) 3–8 (76–203) 10 (254) 3/4–16 x 12-1/8 1/4 (6) 15/16 (24)
CG280A
CG284A*** 15 (381) 4-3/4–11-1/2 (121–292) 13-3/4 (349) 3/4–16 x 18-15/16 3/8 (10) 1 (25)
*Includes CG1 pulling plate. **Two jaw lengths. ***Includes pressure screw extension.
3-JAW PRESSURE SCREW

2-1/2-Ton Capacity (2.3 t), 3-Jaw

Maximum Jaw
Stock Maximum Reach, Maximum Spread, Pressure Screw Jaw Width, TOOLS
No. inches (mm) inches (mm) inside Spread, inches Size, inches Thickness, inches (mm)
(mm) outside inches (mm)
CG243A 2-1/2 (64) 7/8–3-1/4 (22–83) 3 (76) 3/8–16 x 5-1/16 3/16 (5) 3/8 (10)
CG243LA 3-1/2 (89) 7/8–3-3/4 (22–95) 4 (102) 3/8–16 x 6-1/16 3/16 (5) 3/8 (10)
CG243A
6-Ton Capacity (5.4 t), 3-Jaw
Maximum Maximum Jaw
Stock Maximum Spread, Pressure Screw Jaw Width,
No. Reach, inches inches (mm) inside Spread, inches Size, inches Thickness, inches (mm)
(mm) (mm) outside inches (mm)
CG253LA 6 (152) 3/4–8 (19–203) 5/8-18 x 6-7/8 5/8–18 x 6-7/8 5/16 (8) 3/8 (10)
CG253LA
7-1/2-Ton Capacity (6.8 t), 3-Jaw
Maximum Jaw
Stock Maximum Reach, Maximum Spread, Pressure Screw Jaw Width,
No. inches (mm) inches (mm) inside Spread, inches Size, inches Thickness, inches (mm)
(mm) outside inches (mm)
CG253A 3 (76) 1-1/2–3-1/2 (38–89) 4-1/2 (114) 5/8–18 x 6-7/8 1/4 (6) 3/4 (19)
12-1/2-Ton Capacity (11.3 t), 3-Jaw
Maximum Maximum
Reach, Maximum Spread, Spread, Pressure Screw Jaw Jaw Width,
Stock No. Thickness,
inches inches (mm) inside inches (mm) Size, inches inches (mm) CG285A
(mm) outside inches (mm)
CGJ273 5-1/2 (140) 2-1/2–7-1/2 (64–178) 8-1/2 (216) 3/4–16 x 9-13/16 1/4 (6) 15/16 (24)
CG273AA 5-1/2 (140) 2-1/2–7-1/2 (64–178) 8-1/2 (216) 3/4–16 x 9-13/16 1/4 (6) 15/16 (24)
CG283A 8 (203) 3–8 (76–203) 10 (254) 3/4–16 x 12-1/8 1/4 (6) 15/16 (24)
CG285A 15 (381) 4-3/4–11-1/2 (121–292) 13-3/4 (349) 3/4–16 x 18-15/16 3/8 (10) 1 (25)

• Screen the puller application
• Screen the puller application 465
• Inspect the puller, do not use damaged parts
• Inspect the puller, do not use damaged parts
• Use the proper type and size puller for the job
• Use the proper type and size puller for the job
• Read safety precautions on pages W1 to W4
• Read safety precautions on pages W1 to W4
