EXTRACTORS: DOWEL PIN PULLERS

CG503
CG513 CG503-2

CGM503 GENERAL
Dowel Pin Puller CG513-1
Sets Components Set CG503 CGM503 CG503S CG513
Contains:
Stock No. Collet Size Heavy-Duty Housing
CG503-1 Housing (1-3/8ʺ) • • • with Collet
CG503-2 1/4ʺ •
• Collets are threaded to order;
CG503-3 5/16ʺ •
specify stud thread size when
CG503-4 3/8ʺ • ordering (example: CG510
CG503-5 7/16ʺ • 1-3/4ʺ-10 collet)
CG503-6 1/2ʺ • • Avoid bottoming or
CG503-7 9/16ʺ • shouldering the studs
CG503-8 5/8ʺ • to eliminate shearing
CG10F Cross Bar • • • or damaging the stud
CG250-8A Slide Screw, 5/8ʺ-18 UNF x 18-9/16ʺ • • • or workpiece
CG250-9 Slide Hammer, 2 lb • • • CG510 Heavy-Duty Housing HAND
CG503S1 3/8ʺ Square with Collet
CG503-9 6 mm • • For larger stud sizes 1-5/8–2ʺ
CG503-10 8 mm • CG511 Heavy-Duty Housing
CG503-11 10 mm • with Collet
CG503-12 12 mm • • For larger stud sizes 2–2-1/2ʺ
CG503-13 14 mm • CG512 Heavy-Duty Housing
CG503-14 16 mm • with Collet
CG325-6 Nut • • • For larger stud sizes 2-1/2–3ʺ
CG513-1 Housing (2-1/8ʺ)
CG513-2 Slide Screw •
CG513-3 Nut •
CG513-4 3/4ʺ •
CG513-5 7/8ʺ • TOOLS
CG513-6 1ʺ •
CG4567O Slide Hammer, 10 lb •
CG513S1 1/2ʺ Square
CG513S2 5/8ʺ Square

CG500-23 CG500-2
Serrated Collets
CG500P CG505P • Serrated gripping portions are used to remove
unthreaded studs that cannot be removed with standard
Pipe Nipple Remover collets due to lack of gripping surface
• Avoid bottoming or shouldering studs to avoid shearing
Set Components Set CG500P CG505P or damaging stud or workpiece
Contains:
Stock No. Collet Size Housing Stock No. Stock No. Collet Size
CG500P1 1/8ʺ NPT CG500-2 • CG500-20 1/4ʺ Collet
CG500P2 1/4ʺ NPT CG500-2 • CG500-21 5/16ʺ Collet
CG500P3 3/8ʺ NPT CG500-2 • CG500-22 3/8ʺ Collet
CG505P1 1/2ʺ NPT CG505-1 • CG500-23 7/16ʺ Collet
CG505P2 3/4ʺ NPT CG505-1 • CG500-24 1/2ʺ Collet
CG508P1 1ʺ NPT CG508-2 CG500-2 Housing
CG508P2 1-1/4ʺ NPT CG508-2
CG508-2 1-1/8ʺ-12 CG508
CG508 Housing CG500-2
CG500-2 Housing CG500-2 •
CG505-1 Housing CG500-2 •
Note: Avoid bottoming or shouldering the studs to eliminate shearing or
damaging the stud or workpiece.
