Precimar Precimar ICM 100 IP

Dial Indicator Test Device

DESCRIPTION

• With the Precimar ICM 100 IP,
the testing of indicators and
comparators has become auto-
mated and efficient. The simple,
one-handed usability and the
clever operating software make
the Precimar ICM 100 IP the
perfect measurement solution
for inspection rooms, calibration
labs, and routine series testing.
Never before has it been so
efficient to measure indicators
and comparators. With the
Precimar ICM 100 IP, reduce
measurement time by over
60% thanks to faster image
processing, easy-to-use software,
and simpler handling.
• Convenient, tool-free and intui-
tive operation with just one hand TECHNICAL DATA
• Highest-accuracy measurement
through compliance with Abbe‘s Dial indicator testing machines, image processing
principle Positioning speed [mm/s] 4
• Testing to international stan- Type Precimar ICM 100 IP
dards, including ASME/ANSI, Measuring range 100 mm
DIN, BS, JIS, VDI, GOST and NF.
• High-performance USB 3.0 Measuring uncertainty MPE (L in ≤ (0.2 + L/250)
E1
mm) [µm]
industrial camera with high Digital numerical increment [µm] 0.02
image quality and wide
dynamic range Mass [kg] 45
• Robust, industrial-grade LED
ring light for measurements
unaffected by ambient light APPLICATIONS
• Ability to automatically measure • Calibration of dial indicators, dial test indicator
digital indicators through direct measuring devices and dial comparators
reading of values – no cables • The Precimar MSW 100 software system controls the
required dial indicator test device, processes the camera image
• Wide variety of possible test (pointer or numeric display of the test object) and the
specimens up to 4 Inches / 100 reference measuring values of the dial indicator test
mm – dial & digital indicators, device, and also performs all the subsequent processes
comparators, test indicators related to test equipment management.
• Pre-programmed measurement • The testing routine can be implemented based on DIN,
modules with pre-loaded VDI, DKD or DAkkS guidelines, various international
nominal values and tolerances standards, or based on the company’s internal
• Direct measurement range of specifications.
4 inches / 100 mm – no need • Deviations between test objects are illustrated
to reposition the test specimen in a graph during testing.
during testing
• Inductive probes from various
manufacturers can be tested
(only in manual mode)

Supplied with:
• Precimar ICM 100 base device
• Precimar IP 100 upgrade kit
image processing
• Software Precimar MSW V12
• Software option Precimar ICM IP
image processing
• USB cable
• Clamping 8 mm
• Mount for dial test indicators
• Mahr calibration certificate
• Operating manual

For more information, please visit our website: www.mahr.com
