BRAKE: SERVICE TOOLS

Power Steering and Alternator Pullers/Single Pullers
CJ117C Power Steering and Alternator Pulley Puller
• Includes short adaptor to remove small flange-type pulley; long adaptor is
®
used for GM 200-platform vehicles SHOP
®
• Can also remove Chrysler alternator pulleys that have double grooves
• Replace pulleys with CJ113B Installer
®
• Long adaptor included to handle pulleys on GM minivans
• Nickel-chrome finish, industrial-finish screw CJ117C
• Designed for most US vehicles (replace pulley with CJ122 sets)
Disc Brake Tools
BRHC2PK Kit, Brake Rotor Holding Clips, 2 pc
• Allows for easy reinstallation of brake caliper, caliper bracket and pads
• Stabilizes the rotor to the hub
• Ergonomic grip for ease of use
• Clips made of hardened steel
• Includes (2) clips BRHC2PK
BTPUCK2 Two Pin Brake Piston Tool
• Universal and adjustable twin pin brake caliper piston resetting puck
eliminates need for 15 or more different sized pucks to service brakes on a EQUIPMENT
vast majority of vehicles on the road today
• Fully adjustable rotating body dials in the twin pins distance (center to
center) for easy insertion into brake caliper piston face slots
• Slim-profile allows for easy access and quick service of narrow and/or
micro-type calipers
• Services nearly every wind-back brake caliper piston with 2 or 4 faced slots
• Easily works with a 3/8 ratchet or any Wind-back type tool
• Exclusive Rotating lock secures the twin pin spread/stroke, maintaining BTPUCK2
perfect fit every time
BTPUCK3 Three Pin Brake Piston Tool
• Pins fully adjust and mate up to bores on brake piston surface
• For use on vehicles that have a disc brake caliper equipped with a singular
piston and the emergency/parking brake system is incorporated within
this brake caliper housing
• Tool resets the brake piston on calipers equipped with an Electric Parking
Brake (EPB); not applicable to multi-piston calipers
• 3 Pin Puck for Audi equipped with EPB BTPUCK3
®

Truck Brake Tools
CPP16 Extended Heavy-Duty Clutch Pin Punch
• Overall length of 16ʺ to access and perform routine maintenance on recessed and
hard-to-reach roll pins
• Solid through pin prevents unnecessary stress or impact on handle
• Striking end of pin extends 1/4ʺ to protect handle from being damaged when in use CPP16
®
®
• Snap-on Instinct soft handle for improved grip, comfort and turning power
• Constructed of hardened steel; made in the USA
HONES

Three Arm Hones and Stone Sets
CF63A ‡ Three Arm Hone (Blue-Point )
®
• For 3/4–2-1/2ʺ dia. cylinders
• Adjustable thumb nut to control tension
Stock No. Grit Length, inches
CF63A-100 100 (3) 1-1/8
CF63A-240 240 (3) 1-1/8 CF63A
CF63A-400 400 (3) 1-1/8

• Do not use chrome or industrial finish hand tools with impact drivers
• Do not use “cheater bars” on handles
• Operate hone only while it is in cylinder 815
• ‡ These products can expose you to chemicals which are known to the state of California to cause
cancer and reproductive harm. See pages 906-907 for details.
• Read safety precautions on pages W1 to W4
