BODY: UNIBODY AND FRAME-STRAIGHTENING EQUIPMENT
EQUIPMENT

Pullers (Body)
CJ107 CJ107 Body Dent Puller
• Slide hammer action pulls out dent for filling
• L-hook included for larger jobs
• 4 lb slide hammer
®
CJ114 Puller, Body Dent, 3 lb Slide Hammer (Blue-Point )
CJ114 • Mainly for rocker, quarter, back and door panels
• Includes screw for puncturing sheet metal with a bodyman hook and
seal hook for larger jobs
• 3 lb slide hammer
YA2002 Quarter Panel Puller (Blue-Point )
®
• Removes dents from rear quarters and wheel wells
• Two 12ʺ tubes (with different dimensions) fit most wheel well openings
• Use with chain attached to frame machine or portable power unit
YA2002
®
CJ1200 Puller Set, Slide Hammer (Blue-Point )
• Contains a 12 lb, contour-formed slide hammer and a variety of
attachments for auto body repair work
Alignment Bar
BM175 Alignment Bar (Blue-Point )
®
• Use to align bumpers, window posts, wheel wells, panels, hoods,
SHOP BODY: BODY REPAIR • 4-1/2ʺ long, 1-1/2ʺ dia. tubing
decks and brackets
• 6ʹ, 1/4ʺ chain has hooks welded to each end for easy attachment to
body components
CJ1200

Body Repair Kits
®
YA1544A Body Repair Kit (Blue-Point )
• 4-ton capacity model provides the pushing and spreading power
needed to make fast and easy work of everyday repairs
• Auto pump overload system protects against damage to rams
and equipment
• 1/2-ton capacity hydraulic spreader has 2ʺ jaw and spreads from
5/8ʺ–3-3/4ʺ
• Flex head includes a permanently molded rubber pad
• Heavy walled extension tubes stand up to the toughest loads
• Long handle reduces required pumping effort
• 18-pc 4-ton capacity kit includes a hydraulic unit, (5) Snap-Set
YA1544A extensions, a spreader, a full selection of attachments for most push
applications and a durable storage case
®
YA1545 10 Ton Body Repair Kit (Blue-Point )
• 10-ton capacity kit includes (1) hydraulic unit, (4) extensions
(4, 10, 18 and 27ʺ), a spreader and a full selection of attachments
in a custom-fitted, rugged and wheeled storage case
• Pumps are rated from 8,000–10,000 PSI
• Portable for use on the road or in the shop
YA1545

Push-Pull Jack
®
BM101 Push-Pull Jack (Blue-Point )
• Capable of 3,000 lb push-pull power
• Aligns, straightens and removes dents
• Multipurpose hook on jack head and a hook on the 55ʺ long friction rod
BM101 • Friction rod flexes to maintain constant pressure without bending,
while the grooved end prevents slipping
• Three-position handle
