TORQUE MEASUREMENT

Calibration details
STATIC TRANSDUCERS

Static Transducers 11/2" through to 31/2" Male to Female (M/F)
4 STATIC TRANSDUCERS - 250 - 7,000 N·m
50703.xxx 250 - 2,500 N�m 1 ∕ 2" M/F
1
50791.xxx 300 - 3,000 N�m 1 ∕ 2" M/F
1
50599.xxx 500 - 5,000 N�m 1 ∕ 2" M/F
1
50669.xxx@ 700 - 7,000 N�m 1 ∕ 2" M/F
1
4 STATIC TRANSDUCERS - 250 - 5,000 lbf·ft
50704.xxx 250 - 2,500 lbf�ft 1 ∕ 2" M/F
1
50630.xxx 500 - 5,000 lbf�ft 1 ∕ 2" M/F
1
TD5�CCW@ Alternative calibration direction for transducers from
1,501 - 7,000 N�m / 1,001 - 5,000 lbf�ft when ordered with
new unit

4 STATIC TRANSDUCERS - 1,000 - 100,000 N·m
50776.xxx 1,000 - 10,000 N�m 2 ∕ 2" M/F
1
50797.xxx 2,500 - 25,000 N�m 2 ∕ 2" M/F
1
50781.xxx 5,000 - 50,000 N�m 2 ∕ 2" M/F
1
50783.xxx 8,000 - 80,000 N�m 3 ∕ 2" M/F
1
50816.xxx 10,000 - 100,000 N·m 3 ∕ 2" M/F
1
4 STATIC TRANSDUCERS - 1,000 - 60,000 lbf·ft
50777.xxx 1,000 - 10,000 lbf�ft 2 ∕ 2" M/F
1
50798.xxx 2,500 - 25,000 lbf�ft 2 ∕ 2" M/F Model 11/2" M/F 21/2" M/F 31/2" M/F
1
50799.xxx 3,000 - 30,000 lbf�ft 2 ∕ 2" M/F
1
50782.xxx 6,000 - 60,000 lbf�ft 3 ∕ 2" M/F 50703.xxx 50776.xxx
1
50791.xxx
50797.xxx
50599.xxx 50781.xxx 50783.xxx
Part Number 50669.xxx 50777.xxx 50816.xxx
TD3�CCW+ Alternative calibration direction for transducers from 50704.xxx 50798.xxx 50782.xxx
7,001 - 100,000 N�m / 5,001 - 100,000 lbf�ft when ordered 50630.xxx 50799.xxx
with new unit
ØA 95 130 160
B 59 80 107
xxx Indicates .LOG or .IND versions, please see page 98.
* .LOG versions not suitable for use with TST, TTT or TTL-HE, purchased Dimensions C 160 209 292
pre Feb 2016� (mm) D 41 59 91
@ UKAS accredited calibration up to 6,000 N�m. A non-accredited value E 85 114 147
at 7,000 N�m is extrapolated and provided for reference only.
+ UKAS accredited calibration up to 80,000 lbf�ft. A non-accredited value F 38 57 76
at 100,000 lbf�ft is extrapolated and provided for reference only. Weight (kg) 4.5 11.5 16.5
