TORQUE MEASUREMENT

PROFESSIONAL TORQUE TESTER (PRO-TEST)
Calibration details

The Professional Torque Tester (Pro-Test) - Series 2, is an accurate, highly specified and easy to operate
instrument for testing and calibrating all types of torque wrench.
The Pro-Test is supplied as standard with a UKAS accredited calibration
certificate.
• Pro-Test is priced to make in-house testing a viable proposition even for the smaller
industrial and automotive torque wrench user
• Guaranteed classification to BS7882:2017, Class 1 or better over the primary calibration
range (20% to 100% of full scale), Class 2 or better over the secondary calibration range
(lowest calibrated value to 20% of full scale). Class 1 equates to ±0.5% of reading
• Three essential operating modes allow the Pro-Test to be used with all torque wrench types
‘Track’ displays the live value, ‘Peak Memory’ records the highest value and ‘First Peak Memory’
records the first peak of torque (for click type torque wrenches). Both memory modes can be used
with manual or automatic reset
• Large backlit display is easily visible from a distance and in poor light
• Display and transducer are hard-wired together with a 600 mm cable
• All common units of torque measurement are included
• Pictorial mode selection incorporated for ease of use
• User can select the language they wish to work in (most European languages are included)
• Transducer can be mounted for torque wrench operation in the horizontal or vertical plane
• RS-232-C is included for the output of reading to a printer, PC, data capture unit, SPC software etc
• Optional mounting plate gives greater flexibility of mounting options
• All user-settable parameters are menu selectable from the front panel
• Supplied in a robust carry case with a data transfer lead to connect to a PC or printer
• All transducers are supplied as standard with a UKAS accredited calibration certificate in CW direction. For additional counter-
clockwise direction order: Part No. PROTEST.CCW

4 PRO-TEST SERIES 2
43218 Pro-Test 60, 1.2 - 60 N�m
43219 Pro-Test 400, 8 - 400 N�m
43220 Pro-Test 1500, 30 - 1,500 N�m

4 ANCILLARY PRODUCTS FOR PRO-TEST
62198.BLK9005 Mounting Bracket
60253 12v DC Power Supply for Series 2
29190 1" x 36 mm socket
29179 3 ∕ 4" x 36 mm socket
29143 1 ∕ 2" x 36 mm socket
29083 3 ∕ 8" x 36 mm socket
PROTEST�CCW Counter-clockwise calibration when ordered with new
unit

Model Pro-Test 60 Pro-Test 400 Pro-Test 1500
Part Number 43218 43219 43220
1/4" to 10 mm Hex 3/8" to 22 mm Hex
Socket(s) provided 3/8" to 10 mm Hex 1/2" to 22 mm Hex 3/4" to 36 mm Hex
1/2" to 10 mm Hex 3/4" to 22 mm Hex
ØA 12 12 12
B 55 55 55
C 183 183 183
Dimensions D 18 18 18
(mm) E 70 70 70
F 185 185 185
G 233 233 233
H 106 106 106
Weight (kg) 6�3 6�4 7�3
