TORQUE MEASUREMENT

TRUCHECK™ 2 (3 - 2,100 N·m)

4 TRUCHECK 2 (3 - 2,100 N·m)
43520* TruCheck 2, 3 - 65 N�m TruCheck™ 2 Plus
43521* TruCheck 2 Plus, 3 - 65 N�m 1,100 N·m
43522 + TruCheck 2, 10 - 260 lbf�ft
43523 + TruCheck 2 Plus, 10 - 260 lbf�ft
43524 + TruCheck 2, 10 - 350 N�m
43525 + TruCheck 2 Plus, 10 - 350 N�m
43528 @ TruCheck 2, 40 - 800 lbf�ft
43529 @ TruCheck 2 Plus, 40 - 800 lbf�ft
43530 @ TruCheck 2, 50 - 1,100 N�m
43531 @ TruCheck 2 Plus, 50 - 1,100 N�m
43532 ^ TruCheck 2, 200 - 2,100 N�m
43533 ^ TruCheck 2 Plus, 200 - 2,100 N�m
TCACC�CW UKAS accredited calibration - clockwise
TCACC� UKAS accredited calibration - clockwise and
CW+CCW counter-clockwise
TruCheck™ 2 Plus

* 43520 and 43521 supplied with ∕ 8" female square drive 350 N·m
3
+ 43522, 43523, 43524 and 43525 supplied with ∕ 2" female square drive
1
@ 43528, 43529, 43530 and 43531 supplied with 27 mm male hexagon plus
3 ∕ 4" female sq. dr. adapter
^ 43532 and 43533 supplied with 27 mm male hexagon plus 1" female sq.
dr� adapter
NOTE: If you order a UKAS accredited calibration, this certificate will be
provided in place of the traceable calibration certificate and over the
operating range as indicated on the device.

TruCheck 2/Plus TruCheck 2/Plus
TruCheck™ 2 Plus 1100 shown with a Power Tool Test Fixture (not included - see Model 3 - 65 N·m 40 - 800 lbf·ft
page 113) allowing for cost-effective checking of power tools 10 - 260 lbf·ft 50 - 1,100 N·m
10 - 350 N·m 200 - 2,100 N·m
43520, 43521, 43528, 43529,
Part 43522, 43523, 43530, 43531,
Number
43524, 43525 43532, 43533
A 110 120
B 95 105
C 40 40
60
50
D E 117 133
Dimensions (mm) F G 138 138
67
59
ØH 10.5 10.5
J 19 19
K 80 95
L 19 20
Weight (kg) 2�6 3.5

enquiry@norbar�com | www�norbar�com 92
