Page 88 - 诺霸英文2022

POWERED TORQUE TOOLS

LUBRO CONTROL UNITS

Lubro Control Unit, part numbers 16074 and 60339
Norbar’s standard filter, regulator, lubricator unit 16074 and 60339 feature
a 100 mm diameter gauge for easy and accurate setting of air pressure
with ergonomic placement of air pressure adjustment control. Supplied
with 3 metres of robust, steel braided air hose with fittings to connect to
PneuTorque® wrenches�

Twin Regulator Lubro Control Unit, part number 16075
The ‘Twin Lubro’ has the same features as Norbar’s standard filter,
regulator, lubricator unit but has the benefit of two regulators and a 16074
switch that allows quick selection between two air pressure settings.
A typical application for this would be a PneuTorque® user wishing
to quickly select between two applications requiring different torque
settings. For example, this might be controlled torque in the forward
direction and maximum torque allowed by the tool in the reverse
direction.

Multi Channel Lubro, part number 60290
The Multi Channel Lubro is for users who wish to run their pneumatic
tools at multiple air pressure settings, without having to make time
consuming adjustments to an air regulator. The Multi Channel Lubro
can be programmed for up to 15 air pressure settings and these 16075 60290
settings can be locked by the removal of the programming key. A
typical application would be a tyre shop servicing various vehicles, 11 LUBRO CONTROL UNITS
each vehicle having a different wheel nut torque. Settings can be
recorded on a write-on label situated on the front of the Lubro 16074 Lubro Control Unit with 3 m hose
Control. The Multi Channel Lubro is battery powered with a battery life 60339 MPa only gauged Lubro Control Unit with 3 m hose
of approximately 16 hours under normal use. 16075 Twin Lubro Control Unit with 3 m hose
60290 Multi Channel Lubro with 3 m hose
See page 144 for Lubro Control Unit spares.

SOCKET RETAINERS

These socket retaining clips make attaching sockets to square drives
easy and quick�
8 SOCKET RETAINING CLIPS
19556 Socket Retaining Clip for ∕ 4” sq. dr. (Yellow) - Pack of 10 This product is intended for general purpose use at ground level. It is
3
not intended as a solution for socket retention when working at height
19557 Socket Retaining Clip for 1" sq. dr. (Red) - Pack of 10 or where FOD (foreign object damage) could cause a safety and/or
19558 Socket Retaining Clip for 1 ∕ 2” sq. dr. (Green) - Pack of 10 commercial risk�
1
19559 Socket Retaining Clip for 2 ∕ 2” sq. dr. (Blue) - Pack of 10
1
Not recommened for use with impact tools.
87 enquiry@norbar�com | www�norbar�com
