TORQUE MEASUREMENT

T-BOX™ 2

The T-Box™ 2 utilises its powerful processor to provide a
seamless and complete torque data collection package.
This is capable of tool calibrations, data logging,
simultaneous transducer connections and archiving to
your PC. As standard T-Box™ 2 is supplied with a UKAS
accredited bi-directional calibration certificate recording 61908 TDMS USB Flash Drive
each input as an independent channel.

• Instrument accuracy of ±0.05% (±0.1% when below 10% of • Includes 6 modes for torque tool measurement: Track, Click, Dial &
transducer capacity) Electronic, Stall, Screwdriver and Hydraulic
• System accuracy with a typical Norbar transducer, ±0.5% from 20% • File browser/manager for internal storage and USB management
of transducer capacity giving the user greater ease and flexibility in managing multiple files
• 5 digit resolution when used with any Norbar transducer and folders
• Features a 10.1" multi-touch screen display with on-screen graphic • Can export readings and graphs to CSV and JSON format allowing for
icons for simple and easy tool navigation and selection 3rd party software integration
• Features hardened and impact resistant glass helping to prevent • Ability to network via USB adapter
chips and scratches appearing on the screen’s surface • Continuous output of up to 100 readings per second via RS-232 or
• 2 transducer ports gives you the ability to perform 2 tasks USB virtual serial devices
simultaneously e�g� graphing & measuring • Fast CPU frequency up to 2.3 GHz
• Two task windows allows simultaneous working! Measure against a • Large capacity memory of 120 GB SSD storage
target while graphing the cycle, take readings from two transducers • 4GB RAM allows for smooth and seamless operation
simultaneously, capture two different graphs at the same time or • Bench stand supplied as standard with an adjustable viewing angle
manage and review readings as they are captured • Rear panel features 100 mm x 100 mm VESA mounting holes,
• The T-Box™ 2 can capture graphs up to 325 Hz, offering the ability to allowing for easy wall mounting or the use of third party stands /
analyse fast moving transients arms
• User configurable to allow a selection of torque, torque and angle, • Software can be updated remotely, without the need to return the
rate targets and the ability to set thresholds product to Norbar
• Ability to predefine multiple targets • Fully supports the use of a keyboard and mouse (not supplied)
• 2 USB ports, 1 RS-232 serial port and 2 independantly configurable
ancillary ports 4 T-BOX 2
43542 T-Box 2 Instrument with TDMS Software

Displaying 2 transducer readings simultaneously Storage destination (left) file browser (right) Home menu for 2 separate windows
