TORQUE MEASUREMENT

Calibration details
STATIC TRANSDUCERS

The accuracy and quality of the Norbar Static Torque Transducers has made them the first choice of many calibration laboratories
throughout the world. Up to 5,000 N·m (5,000 lbf·ft) classified to BS7882:2017, typically better than Class 1 for the primary
classification range (±0.5% of reading from 20% to 100% of full scale).

• Robust, heat treated, alloy steel torsion shaft design • Smart transducers have a built in memory circuit which contains essential
• Designed to ignore non-torsional forces information about the transducer. This information can be read by
• Operates in clockwise and counter-clockwise directions Norbar’s TST, TTT, TTL-HE & T-Box™ 2 instruments meaning that when the
• Calibration up to 100,000 N�m with a UKAS accredited certificate transducer is connected, it is immediately recognised and ready for use
• Calibrated in clockwise direction as standard. Counter-clockwise • Smart transducers can also be used with many other instruments,
provided on request however these will operate as normal ratio calibrated (mV/V)
transducers - the smart data will not be read
Static Transducers 1/4" through to 1"
4 STATIC TRANSDUCERS - 0.1 - 1,500 N·m
50587.xxx* 0.1 - 1 N�m 1 ∕ 4" M/F
50588.xxx 0.25 - 2.5 N�m 1 ∕ 4" M/F
50589.xxx 0.5 - 5 N�m 1 ∕ 4" M/F
50590.xxx 1 - 10 N�m 1 ∕ 4" M/F
50591.xxx 2.5 - 25 N�m 3 ∕ 8" M/F
50592.xxx 5 - 50 N�m 3 ∕ 8" M/F
50593.xxx 10 - 100 N�m 1 ∕ 2" M/F
50594.xxx 25 - 250 N�m 1 ∕ 2" M/F
50701.xxx 25 - 250 N�m 3 ∕ 4" M/F
50849.xxx 35 - 350 N·m 1 ∕ 2" M/F
50596.xxx 50 - 500 N�m 3 ∕ 4" M/F
50772.xxx 100 - 1,000 N�m 1" M/F
50766.xxx 150 - 1,500 N�m 1" M/F

4 STATIC TRANSDUCERS - 0.1 - 1,000 lbf·ft Model 1/4" M/F 3/8" M/F 1/2" M/F 3/4" M/F 1" M/F
50611.xxx 0.1 - 1 lbf�ft 1 ∕ 4" M/F 50587.xxx
50588.xxx
50615.xxx 0.5 - 5 lbf�ft 1 ∕ 4" M/F 50589.xxx 50593.xxx
50618.xxx 1 - 10 Ibf�ft 1 ∕ 4" M/F 50590.xxx 50591.xxx 50594.xxx
50620.xxx 2.5 - 25 lbf�ft 3 ∕ 8" M/F 50611.xxx 50592.xxx 50849.xxx 50701.xxx 50772.xxx
50615.xxx
50596.xxx
50836.xxx 5 - 50 lbf�ft 1 ∕ 2" M/F Part Number 50618.xxx 50620.xxx 50836.xxx 50702.xxx 50766.xxx
50773.xxx
50624.xxx
50619.xxx
50624.xxx 10 - 100 lbf�ft 1 ∕ 2" M/F 50610.xxx 50621.xxx 50625.xxx 50627.xxx
50612.xxx
50625.xxx 25 - 250 lbf�ft 1 ∕ 2" M/F 50614.xxx 50623.xxx
50702.xxx 25 - 250 lbf�ft 3 ∕ 4" M/F 50617.xxx
50609.xxx
50627.xxx 50 - 500 lbf�ft 3 ∕ 4" M/F ØA 36 36 36 54 54
50773.xxx 100 - 1,000 lbf�ft 1" M/F
B 33 33 33 42 42
4 STATIC TRANSDUCERS - 1 - 1,000 lbf·in Dimensions C 86 90 93 142 147
(mm)
50610.xxx* 1 - 10 lbf�in 1 ∕ 4" M/F D 10 13 16 24 29
50612.xxx 2.5 - 25 lbf�in 1 ∕ 4" M/F E 30 34 37 46 51
50614.xxx 5 - 50 lbf�in 1 ∕ 4" M/F F 6.5 10 13 22 26
50617.xxx 10 - 100 lbf�in 1 ∕ 4" M/F Weight (kg) 0�6 0�6 0�6 1.5 1�7
50619.xxx 25 - 250 lbf�in 3 ∕ 8" M/F
50621.xxx 50 - 500 lbf�in 3 ∕ 8" M/F
50623.xxx 100 - 1,000 lbf�in 1 ∕ 2" M/F

4 STATIC TRANSDUCERS - 10 - 100 ozf·in
50609.xxx* 10 - 100 ozf�in 1 ∕ 4" M/F

TD2�CCW Alternative calibration direction for transducers up to
1,500 N�m / 1,000 lbf�ft when ordered with new unit

xxx Indicates .LOG or .IND versions, please see page 98.
* .LOG versions not suitable for use with TST, TTT or TTL-HE, purchased
pre Feb 2016�
